Carrier 33CSSP3-FC - Front Panel Overview; Liquid Crystal Display; Control Buttons Functionality

Front Panel
2
Mode Fan
AUTO
COOL
HEAT
1 Liquid Crystal Display with Thermoglow
2 Up/Down Buttons
3 Mode Button
4 Fan/Override Button
5 Heat or Cool Indicator
Heat = Red, Cool = Green
1
3
2
4 5
