MODEL NUMBER NOMENCLATURE
OUTDOOR UNIT
38 HDF 3---01
---
018
Air---Cooled Condenser
Unit Type
HDF --- C o ol i n g O n l y
QRF --- H ea t P u m p
Voltage
3 --- 208/230---1 ---60
5 --- 208/230 ---3 ---60*
6 --- 4 6 0 --- 3 --- 6 0 *
INDOOR UNIT
40 KMC 3---01
---
018
Fan Coil Unit
Unit Type
KMC --- C oo l in g O n l y
KMQ --- H e a t P u mp
Voltage
3 --- 208/230 ---1---60
Nominal Capacity
018 --- 1 --- 1 / 2 To n s
024 --- 2 To n s
030 --- 2 --- 1 / 2 To n s
036 --- 3 To n s
Nominal Capacity
018 --- 1 --- 1 / 2 To n s
024 --- 2 To n s
030 --- 2 --- 1 / 2 To n s
035 or 036 --- 3 To n s
*Size 035 or 036 only
®
Use of the AHRI Certified
TM Mark indicates a
manufacturer’s
participation in the
program For verification
of certification for individual
products, go to
www.ahridirectory.org.
AHRI* CAPACITY RATINGS
System Type Outdoor Section Indoor Section
Standard CFM
Net
Cooling
BTUH
SEER EER
High Heat
Outdoor Indoor BTUH HSPF
Cooling
3 8H D F 0 1 8 --- --- --- 3 4 0 K M C 0 1 8 --- --- --- 3 1720 470 17,000 13 10.9 N/A N/A
3 8H D F 0 2 4 --- --- --- 3 4 0 K M C 0 2 4 --- --- --- 3 1720 690 23,600 13 11.5 N/A N/A
3 8H D F 0 3 0 --- --- --- 3 40KMC 03036 --- --- ---3 1720 910 29,000 13 11.5 N/A N/A
3 8H D F 0 3 6 --- --- --- 3 40KMC 03036 --- --- ---3 3900 910 36,400 13 11.0 N/A N/A
3 8H D F 0 3 6 --- --- --- 5 40KMC 03036 --- --- ---3 3900 910 36,400 13 11.0 N/A N/A
3 8H D F 0 3 6 --- --- --- 6 40KMC 03036 --- --- ---3 3900 910 36,400 13 11.0 N/A N/A
Cooling with
Electric Heat
3 8H D F 0 1 8 --- --- --- 3 40KMQ01824--- --- ---3 1720 690 17,000 13 11.0 N/A N/A
3 8H D F 0 2 4 --- --- --- 3 40KMQ01824--- --- ---3 1720 690 22,600 13 11.0 N/A N/A
3 8H D F 0 3 0 --- --- --- 3 40KMQ03036--- --- ---3 1720 910 29,000 13 11.0 N/A N/A
3 8H D F 0 3 6 --- --- --- 3 40KMQ03036--- --- ---3 3900 910 36,000 13 11.0 N/A N/A
3 8H D F 0 3 6 --- --- --- 5 40KMQ03036--- --- ---3 3900 910 36,000 13 11.0 N/A N/A
3 8H D F 0 3 6 --- --- --- 6 40KMQ03036--- --- ---3 3900 910 36,000 13 11.0 N/A N/A
Heat Pump
3 8Q R F 0 1 8 --- --- --- 3 40KMQ01824--- --- ---3 1720 690 17,900 13 11.0 16,800 7.7
3 8Q R F 0 2 4 --- --- --- 3 40KMQ01824--- --- ---3 1720 690 22,600 13 11.0 20,800 7.7
3 8Q R F 0 3 0 --- --- --- 3 40KMQ03036--- --- ---3 3900 910 29,200 13 11.0 27,400 7.7
3 8Q R F 0 3 5 --- --- --- 3 40KMQ03036--- --- ---3 3900 910 33,400 13 11.0 32,400 7.7
3 8Q R F 0 3 5 --- --- --- 5 40KMQ03036--- --- ---3 3900 910 33,400 13 11.0 32,400 7.7
3 8Q R F 0 3 5 --- --- --- 6 40KMQ03036--- --- ---3 3900 910 33,400 13 11.0 32,400 7.7
*Air Conditioning, Heating & Refrigeration Institute
Legend
HSPF --- Heating Seasonal Performan ce Factor
SEER --- Seasonal Energy Efficiency Ratio
NOTES:
1. Ratings are net values reflecting the effects of circulating fan heat. Ratings are based on: Cooling Standard: 80_F (26.67_C) db, 67_F (19.44_C) wb air
entering indoor unit and 95_F(35_C) db air entering outdoor unit. High Temperature Heating Standard: 70_F (21.11_C) db air entering indoor unit and 47_F
(8.33_C) db, 43_F (6.11_C) wb air entering outdoor unit.
2. Ratings are based on 25 ft. (7.62 m) of interconnecting refrigerant lines.
3. All system ratings are based on fan coil u n its operating at high fan speed. Consult Physical Data tables for airflows at all available fan speeds.
40KMC, KMQ / 38HDF,QRF
