47
No.
Description Part Code
Qty
Product Code CB264N00800 CB264N00300 CB264N00400
1 Guide Lover 10512916 10512916 10512916 1
2 Front Panel 2002240902 2002240902 2002240902 1
3 Stand Bar 10582150P 10582150P 10582150P 1
4 Left Side Plate 26112361B 26112361B 26112361B 1
5 Left Decorative Board 20192600 20192600 20192600 1
6 Left Driving Box Sub- assy 2011220101 2011220101 2011220101 1
7 Decorative Strip (Up) 20192602 20192602 20192602 1
8 Cover plate (Air Outlet) 20122193P 20122193P 20122193P 1
9 Filter Sub- Assy 11122155 11122155 11122155 2
10 Cross Flow Fan 10352054 10352054 10352054 1
11 Ring of Bearing 26152022 26152022 26152022 1
12 O- Gasket sub- assy of Bearing 7651205102 7651205102 7651205102 1
13 Rear Case 2220229602 2220229602 2220229602 1
14 Evaporator Support 24212170 24212170 24212170 1
15 Evaporator Assy 01002658 01002658 01100100162 1
16 Breakwater 26112359 26112359 26112359 1
17 Wall Mounting Frame 01252040 01252040 01252040 1
18 Fan Motor 15012466 15012466 15012466 1
19 Connecting pipe clamp 2611216401 2611216401 2611216401 1
20 Drainage Hose 05230014 05230014 05230014 1
21 Motor Press Plate 26112360 26112360 26112360 1
22 Electric Box Assy 10000201561 10000201382 10000201383 1
23 Deflecting Plate 30070049 30070049 30070049 1
24 Main Board 30138000611 30138000611 30138000611 1
25 Jumper 4202021916 4202021916 4202021916 1
26 Shield Cover of Electric Box Sub- Assy 01592131 01592131 01592131 1
27 Terminal Board 4201026604 4201026604 4201026604 1
28 Display Board 30568247 30568247 30568247 1
29 Air Louver (Middle) 10512336 10512336 10512336 1
30 Helicoid Tongue 2611235702 2611235702 2611235702 1
31 Air Louver 10512766 10512766 10512766 2
32 Swing Lever 10582173 10582173 10582173 1
33
Rear Grill Sub- assy 11002024 11002024 11002024 1
Rear Grill Sub- assy 11002023 11002023 11002023 1
35 Louver Motor Sub- assy (Left and Right) 15002021 15002021 15002021 1
36 Right Decorative Board 20192601 20192601 20192601 1
37 Right Side Plate 26112362B 26112362B 26112362B 1
38 Front Case 20022410B 20022410B 20022410B 1
39 Screw Cover 24252029P 24252029P 24252029P 3
40 Electric Box Cover Sub- Assy 00001300010 00001300010 00001300010 1
41 Remote Controller 30510568 30510568 30510568
