DIMENSIONS (CONT.)
Fig. 2 —Indoor Unit (Sizes 24-48K)
Table 2 — Dimensions
MODEL (KBtu/h) UNIT A
24
inch 8.07
mm 205
36
inch 9.65
mm 245
48
inch 11.30
mm 287
30-3/8 (770)
3 (75)
26-3/8 (670)
32-5/8 (830)
26-3/8 (670)
32-5/8 (830)
1 (25)
5-5/8 (142)
3-7/8 (98)
5-3/4 (146)
5-1/2 (139)
4 (101)
37-3/8 (950)
37-3/8 (950)
A
