Barometric Pressure R/W IN_HG_OF_KPAG barp AV:161 10 to 35 BARP
Block No: in Master Zone R/W lnk_mzbk AV:262 0 to 255 LNK_MZBK
CCH Max Temperature R/W °F cch_max_t AV:2 40 to 90 CCHMAXT
CCH1 Relay Resets Count READ ONLY rs_cchr1 AV:294 0 to 65535 RS_CCHR1
CCH1 Relay Run Hours READ ONLY hrs hour_cchr1 AV:242 0 to 999999 HR_CCHR1
CCH1 Relay Starts READ ONLY st_cchr1 AV:301 0 to 999999 ST_CCHR1
Change Filter Timer R/W hrs filter_service_hrs AV:2019 0 to 9999 FILTLIFE
Change of value for IAQ R/W coviaq AV:8015 0 to 60 COVIAQ
Change of value for OAQ R/W covoaq AV:8016 0 to 60 COVOAQ
Change of value for OARH R/W covoarh AV:8018 0 to 60 COVOARH
Change of value for OAT R/W covoat AV:8017 0 to 60 COVOAT
Change of value for RARH R/W covrarh AV:8019 0 to 60 COVRARH
Change of value for RAT R/W covrat AV:8020 0 to 60 COVRAT
Change of value for SPRH R/W covsprh AV:8030 0 to 60 COVSPRH
Change of value for SPT R/W covspt AV:8021 0 to 60 COVSPT
Cir.A Discharge Pressure R/W PSI sdp_a AV:124 –67.06 to 699.63 SDP_A
Cir.A Sat.Discharge Temp READ ONLY °F sdt_a AV:295 –100 to 500 SDT_A
Cir.A Sat.Suction Temp READ ONLY °F sst_a AV:339 –100 to 500 SST_A
Cir.A Suction Pressure READ ONLY PSI ssp_a AV:131 –47.33 to 430.16 SSP_A
Circuit A Pressure Ratio READ ONLY cira_pr AV:204 14.5 to 667.0 CIRA_PR
CLV_A Resets Count READ ONLY rs_clv_a AV:455 0 to 65535 RS_CLV_A
CLV_A Run Hours READ ONLY hrs hr_clv_a AV:457 0 to 999999 HR_CLV_A
CLV_A Starts READ ONLY st_clv_a AV:459 0 to 999999 ST_CLV_A
CMP A1 Loader Run Hours READ ONLY hrs hr_aldr AV:7010 0 to 999999 HR_ALDR
CMP A1 Loader Starts READ ONLY st_aldr AV:7011 0 to 999999 ST_ALDR
cmp Loader Timeguard READ ONLY sec timg_ald AV:164 0 to 600 TIMG_ALD
Commanded IDF Speed READ ONLY % sf_vfd_feedback AV:6 –2 to 2 FANFB
Commanded IDF Speed READ ONLY % vfd_output AV:2027 0.0f to 1.0f FANSPEED
Commanded ODF Speed READ ONLY RPM odf_out_speed AV:87 0 to 2000 ODFSPD
Comp A1 Resets Count READ ONLY rs_a1 AV:97 0 to 65535 RS_A1
Comp A2 Resets Count READ ONLY rs_a2 AV:98 0 to 65535 RS_A2
Compressor A1 Run Hours READ ONLY hrs hour_a1 AV:47 0 to 999999 HR_A1
Compressor A1 Run Hours READ ONLY hrs hr_rlv_a AV:458 0 to 999999 HR_RLV_A
Compressor A1 Starts READ ONLY st_a1 AV:134 0 to 999999 ST_A1
Compressor A1 strikes READ ONLY a1strike AV:192 0 to 3 A1STRIKE
Compressor A1 Timeguard READ ONLY sec timgd_a1 AV:162 0 to 600 TIMGD_A1
Compressor A2 Run Hours READ ONLY hrs hour_a2 AV:48 0 to 999999 HR_A2
Compressor A2 Starts READ ONLY st_a2 AV:135 0 to 999999 ST_A2
Compressor A2 Strikes READ ONLY a2strike AV:193 0 to 3 A2STRIKE
Compressor A2 Timeguard READ ONLY sec timgd_a2 AV:157 0 to 600 TIMGD_A2
Compressor Min Off Time R/W sec c_minoff AV:202 120 to 600 C_MINOFF
Compressor Min On Time R/W sec c_minon AV:203 180 to 600 C_MINON
COOL DMD Offset level 1 R/W °F cdlm_level1 AV:400 0 to 40 CLDOLEV1
COOL DMD Offset level 2 R/W °F cdlm_level2 AV:401 0 to 40 CLDOLEV2
COOL DMD Offset level 3 R/W °F cdlm_level3 AV:402 0 to 40 CLDOLEV3
Cool Mode Select T.guard READ ONLY sec cl_sel_timeguard AV:40 0 to 65535 COOLMSTG
Cool Setpoint in Effect READ ONLY °F csp_eff AV:208 55 to 95 CSP_EFF
Cool Shed 1 demand band R/W coolsh1 AV:6014 0 to 55 COOLSH1
Cool Shed 2 demand band R/W coolsh2 AV:6015 0 to 55 COOLSH2
Cool Shed 3 demand band R/W coolsh3 AV:6016 0 to 55 COOLSH3
Cooling Demand Trend
READ ONLY cldtrend AV:205 –99 to 99 CLDTREND
Cooling Fan-Off Delay R/W sec cool_fod AV:207 0 to 600 COOL_FOD
Damper Actual Position R/W % oa_dmpr_pos AV:2022 0 to 1 DAMPPOS
Damper SAT deadband R/W °F t24satdb AV:308 0 to 20 T24SATDB
Delay On Low SST Check R/W sec sstckdly AV:300 0 to 300 SSTCKDLY
Diff. Dry Bulb Deadband R/W °F oa_ra_diff_temp AV:78 1.0f to 99.0f OATRATDB
Differential Air Quality READ ONLY PPM aq_diff AV:195 –5000 to 5000 AQ_DIFF
Econ Damper Resets Count READ ONLY rs_damp AV:102 0 to 65535 RS_DAMP
Econ Damper Run Hours READ ONLY hrs hour_damp AV:51 0 to 999999 HR_DAMP
Econ Max Damper Position R/W % dampmax AV:185 0 to 1 DAMPMAX
Econ Min at Max Fanspeed R/W % minp_max AV:318 0 to 1 MINP_MAX
Table Y — BACnet* AV Points List (cont)
POINT DESCRIPTION POINT ACCESS UNITS
BACNET
OBJECT NAME
BACNET
ID
VALUE
RANGE
CCN POINT
EQUIVALENT
