94
APPENDIX V. MOTORMASTER SENSOR LOCATIONS
SENSOR
LOCATION
C12258
Fig. 85 − Motormaster Sensor Locations − D17, D20, and D24
SENSOR
LOCATION
C12259
Fig. 86 − Motormaster Sensor Location − D28
Copyright 2015 Carrier Corp. 7310 W. Morris St. Indianapolis, IN 46231 Edition Date: 12/15
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
Catalog No: 48TC-17-30-01SM
Replaces: NEW
