APPENDIX C — FAN PERFORMANCE
50FC-M05 THREE PHASE – MEDIUM STATIC — 4 TON HORIZONTAL SUPPLY (RPM - VDC)
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
RPM Vdc RPM Vdc RPM Vdc RPM Vdc RPM Vdc
1200
1093 5.0 1306 6.0 1497 6.9 1667 7.7 1819 8.4
1300
1148 5.3 1348 6.2 1533 7.1 1700 7.8 1850 8.5
1400
1206 5.6 1393 6.4 1571 7.2 1734 8.0 1883 8.7
1500
1266 5.8 1442 6.6 1612 7.4 1770 8.2 1916 8.8
1600
1329 6.1 1493 6.9 1655 7.6 1808 8.3 1951 9.0
1700
1393 6.4 1546 7.1 1700 7.8 1848 8.5 1988 9.2
1800
1458 6.7 1602 7.4 1747 8.1 1890 8.7 2026 9.3
1900
1523 7.0 1659 7.6 1797 8.3 1934 8.9 2066 9.5
2000
1590 7.3 1718 7.9 1849 8.5 1980 9.1 2108 9.7
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
RPM Vdc RPM Vdc RPM Vdc RPM Vdc RPM Vdc
1200
1959 9.0 2089 9.6——————
1300
1988 9.2 2117 9.8——————
1400
2019 9.3 2146 9.9——————
1500
2052 9.5————————
1600
2084 9.6————————
1700
2119 9.8————————
1800
2154 9.9————————
1900 ——————————
2000 ——————————
Medium Static 1093-2170 RPM
50FC-M05 THREE PHASE – HIGH STATIC — 4 TON HORIZONTAL SUPPLY (RPM - VDC)
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
RPM Vdc RPM Vdc RPM Vdc RPM Vdc RPM Vdc
1200
1093 4.1 1306 4.9 1497 5.6 1667 6.3 1819 6.8
1300
1148 4.3 1348 5.1 1533 5.8 1700 6.4 1850 7.0
1400
1206 4.5 1393 5.2 1571 5.9 1734 6.5 1883 7.1
1500
1266 4.8 1442 5.4 1612 6.1 1770 6.7 1916 7.2
1600
1329 5.0 1493 5.6 1655 6.2 1808 6.8 1951 7.3
1700
1393 5.2 1546 5.8 1700 6.4 1848 6.9 1988 7.5
1800
1458 5.5 1602 6.0 1747 6.6 1890 7.1 2026 7.6
1900
1523 5.7 1659 6.2 1797 6.8 1934 7.3 2066 7.8
2000
1590 6.0 1718 6.5 1849 7.0 1980 7.4 2108 7.9
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
RPM Vdc RPM Vdc RPM Vdc RPM Vdc RPM Vdc
1200
1959 7.4 2089 7.9 2211 8.3 2327 8.7 2438 9.2
1300
1988 7.5 2117 8.0 2238 8.4 2352 8.8 2462 9.3
1400
2019 7.6 2146 8.1 2266 8.5 2379 8.9 2487 9.3
1500
2052 7.7 2177 8.2 2296 8.6 2408 9.1 2515 9.5
1600
2084 7.8 2209 8.3 2327 8.7 2438 9.2 2544 9.6
1700
2119 8.0 2242 8.4 2358 8.9 2469 9.3 2574 9.7
1800
2154 8.1 2276 8.6 2391 9.0 2500 9.4 2605 9.8
1900
2191 8.2 2311 8.7 2424 9.1 2533 9.5 2636 9.9
2000
2230 8.4 2347 8.8 2459 9.2 2566 9.6 ——
High Static 1093-2660 RPM
