APPENDIX C — FAN PERFORMANCE
50FC-M07 THREE PHASE — 6 TON HORIZONTAL SUPPLY (RPM - BHP)
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1800
1379 0.27 1512 0.35 1650 0.46 1786 0.58 1918 0.72
1950
1473 0.32 1594 0.41 1721 0.52 1848 0.64 1973 0.78
2100
1569 0.39 1680 0.48 1796 0.59 1915 0.71 2032 0.85
2250
1666 0.47 1769 0.56 1876 0.67 1986 0.79 2096 0.93
2400
1764 0.55 1860 0.65 1959 0.76 2061 0.88 2165 1.02
2550
1863 0.65 1952 0.75 2045 0.86 2140 0.99 2237 1.13
2700
1963 0.76 2047 0.86 2133 0.97 2222 1.10 2313 1.24
2850
2063 0.88 2142 0.99 2223 1.10 2307 1.23 2393 1.37
3000
2163 1.01 2238 1.12 2315 1.24 2394 1.37 2474 1.52
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1800
2044 0.87 2163 1.03 2276 1.20 2383 1.38 2486 1.57
1950
2094 0.93 2210 1.10 2320 1.27 2426 1.45 2527 1.64
2100
2148 1.00 2260 1.17 2367 1.34 2471 1.53 2570 1.72
2250
2206 1.08 2313 1.25 2417 1.43 2518 1.61 2616 1.81
2400
2268 1.18 2371 1.34 2471 1.52 2569 1.71 2664 1.90
2550
2335 1.28 2432 1.45 2528 1.62 2622 1.81 2715 2.01
2700
2405 1.40 2497 1.56 2589 1.74 2680 1.93 2769 2.13
2850
2479 1.53 2566 1.69 2654 1.87 2740 2.06 2826 2.26
3000
2556 1.67 2639 1.84 2722 2.02 2804 2.21 ——
Standard Static 1379-2300 RPM, 1.31 Max BHP
Medium Static 1379-2530 RPM, 1.76 Max BHP
High Static 1379-2836 RPM, 2.43 Max BHP
50FC-M07 THREE PHASE – STANDARD STATIC — 6 TON HORIZONTAL SUPPLY (RPM - VDC)
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
RPM Vdc RPM Vdc RPM Vdc RPM Vdc RPM Vdc
1800
1379 6.0 1512 6.6 1650 7.2 1786 7.8 1918 8.3
1950
1473 6.4 1594 6.9 1721 7.5 1848 8.0 1973 8.6
2100
1569 6.8 1680 7.3 1796 7.8 1915 8.3 2032 8.8
2250
1666 7.2 1769 7.7 1876 8.2 1986 8.6 2096 9.1
2400
1764 7.7 1860 8.1 1959 8.5 2061 9.0 2165 9.4
2550
1863 8.1 1952 8.5 2045 8.9 2140 9.3 2237 9.7
2700
1963 8.5 2047 8.9 2133 9.3 2222 9.7 — —
2850
2063 9.0 2142 9.3 2223 9.7 — — — —
3000
2163 9.4 2238 9.7——————
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
RPM Vdc RPM Vdc RPM Vdc RPM Vdc RPM Vdc
1800
2044 8.9 2163 9.4 2276 9.9 — — — —
1950
2094 9.1 2210 9.6——————
2100
2148 9.3 2260 9.8——————
2250
2206 9.6————————
2400
2268 9.9————————
2550 ——————————
2700 ——————————
2850 ——————————
3000 ——————————
Standard Static 1379-2300 RPM
