APPENDIX C — FAN PERFORMANCE
50FC-M07 THREE PHASE – MEDIUM STATIC — 6 TON HORIZONTAL SUPPLY (RPM - VDC)
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
RPM Vdc RPM Vdc RPM Vdc RPM Vdc RPM Vdc
1800
1379 5.5 1512 6.0 1650 6.5 1786 7.1 1918 7.6
1950
1473 5.8 1594 6.3 1721 6.8 1848 7.3 1973 7.8
2100
1569 6.2 1680 6.6 1796 7.1 1915 7.6 2032 8.0
2250
1666 6.6 1769 7.0 1876 7.4 1986 7.8 2096 8.3
2400
1764 7.0 1860 7.4 1959 7.7 2061 8.1 2165 8.6
2550
1863 7.4 1952 7.7 2045 8.1 2140 8.5 2237 8.8
2700
1963 7.8 2047 8.1 2133 8.4 2222 8.8 2313 9.1
2850
2063 8.2 2142 8.5 2223 8.8 2307 9.1 2393 9.5
3000
2163 8.5 2238 8.8 2315 9.2 2394 9.5 2474 9.8
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
RPM Vdc RPM Vdc RPM Vdc RPM Vdc RPM Vdc
1800
2044 8.1 2163 8.5 2276 9.0 2383 9.4 2486 9.8
1950
2094 8.3 2210 8.7 2320 9.2 2426 9.6 2527 10.0
2100
2148 8.5 2260 8.9 2367 9.4 2471 9.8 — —
2250
2206 8.7 2313 9.1 2417 9.6 2518 10.0 — —
2400
2268 9.0 2371 9.4 2471 9.8————
2550
2335 9.2 2432 9.6 2528 10.0————
2700
2405 9.5 2497 9.9——————
2850
2479 9.8————————
3000 ——————————
Medium Static 1379-2530 RPM
50FC-M07 THREE PHASE – HIGH STATIC — 6 TON HORIZONTAL SUPPLY (RPM - VDC)
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
RPM Vdc RPM Vdc RPM Vdc RPM Vdc RPM Vdc
1800
1379 4.9 1512 5.3 1650 5.8 1786 6.3 1918 6.8
1950
1473 5.2 1594 5.6 1721 6.1 1848 6.5 1973 7.0
2100
1569 5.5 1680 5.9 1796 6.3 1915 6.8 2032 7.2
2250
1666 5.9 1769 6.2 1876 6.6 1986 7.0 2096 7.4
2400
1764 6.2 1860 6.6 1959 6.9 2061 7.3 2165 7.6
2550
1863 6.6 1952 6.9 2045 7.2 2140 7.5 2237 7.9
2700
1963 6.9 2047 7.2 2133 7.5 2222 7.8 2313 8.2
2850
2063 7.3 2142 7.6 2223 7.8 2307 8.1 2393 8.4
3000
2163 7.6 2238 7.9 2315 8.2 2394 8.4 2474 8.7
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
RPM Vdc RPM Vdc RPM Vdc RPM Vdc RPM Vdc
1800
2044 7.2 2163 7.6 2276 8.0 2383 8.4 2486 8.8
1950
2094 7.4 2210 7.8 2320 8.2 2426 8.6 2527 8.9
2100
2148 7.6 2260 8.0 2367 8.3 2471 8.7 2570 9.1
2250
2206 7.8 2313 8.2 2417 8.5 2518 8.9 2616 9.2
2400
2268 8.0 2371 8.4 2471 8.7 2569 9.1 2664 9.4
2550
2335 8.2 2432 8.6 2528 8.9 2622 9.2 2715 9.6
2700
2405 8.5 2497 8.8 2589 9.1 2680 9.4 2769 9.8
2850
2479 8.7 2566 9.0 2654 9.4 2740 9.7 2826 10.0
3000
2556 9.0 2639 9.3 2722 9.6 2804 9.9 ——
High Static 1379-2836 RPM
