OWNER
’
S GUIDE -
5
Names and Functions of the Buttons
1. On/Off Button
2. Mode Selector Button
3. Fan Speed Selector Button
4. On Timer Button
5. Temperature Selector Buttons
6. Off Timer Button
1 2
MODE SELECTOR BUTTON - Press this button to
select the desired mode. In COOL mode, the unit
will run at the normal cooling mode. In DRY mode,
the microcomputer of the unit controls the fan
motor and makes the unit automatically cycle on
and off according to the room temperature. This
enables the moisture to be removed more
efficiently. In FAN mode, only the fan will operate
at the selected fan speed and circulate the room
air. In HEAT mode, the unit will run at the normal
heat pump mode. And in FURN. mode, the unit
will run at the normal furnace mode (This
is a user optional function.).
ON/OFF BUTTON - If you press this button, the unit
will begin operation. (You can hear receiving
beeps twice.) Press the button again, and opera-
tion stops. (You can hear a receiving beep.) If you
press this button immediately after turning off the
unit, the compressor will not operate for 3 minutes
to prevent overloading.
REMOTE CONTROL DESCRIPTIONS
FAN
SPEED
ON/OFF
MODE
FURN.
COOL
DRY
FAN
HEAT
AUTO
LOW
HIGH
TEMP.
F
C
ON
TIMER
OFF
TIMER
TIMER
OFFON
*
TEST MODE
: Installer can operate the unit anytime regardless of temperature by pushing Emergency Button
(COOL or HEAT) more than 5 seconds continuously after installing the unit. (This function is only used by
servicemen to test the unit operation.)
*
Refrigerant Compressor Time Delay
: The air conditioning system is equipped with a time delay on the
compressor during the start of the cooling cycle. This time delay may be up to 3 minutes at the time of start up.
햷 REMOTE CONTROL SIGNAL RECEIVER
If you want to stop the emergency operation, push the EMERGENCY button again or operate
the remote control.
NOTE
To Next Page
