29
30XBP 850 900 1000 1100 1200 1300 1400 1500
Capacity control SmartVu
TM
, Electronic Expansion Valve (EXV)
Minimum capacity % 15 15 15 15 15 15 15 15
Air heat exchanger Aluminum micro-channel coils (MCHE)
Fans FLYING-BIRD 6, axial fan with rotating impeller
Standard unit
Quantity 14 14 16 19 20 20 20 22
Maximum total air ow l/s 67480 67480 77120 91580 96400 96400 96400 106040
Maximum rotation speed r/s 15,7 15,7 15,7 15,7 15,7 15,7 15,7 15,7
Unit + option 15LS
Maximum total air ow l/s 55020 55020 62880 78600 78600 78600 78600 86460
Maximum rotation speed r/s 11,7 11,7 11,7 11,7 11,7 11,7 11,7 11,7
Water heat exchanger Flooded multi-pipe type
Water volume l 119 130 140 164 174 180 189 189
Max. water-side operating pressure without hydraulic module kPa 1000 1000 1000 1000 1000 1000 1000 1000
Hydraulic module (option)
Pump, Victaulic screen lter, relief valve, water and air drain valve,
pressure sensors, expansion tank (option)
Pump
Centrifugal pump, monocell, 48,3r/s, low or high pressure (as required),
single or dual (as required)
Expansion vessel volume inch
Max. water-side operating pressure with hydraulic module mm
Water connections Victaulic
®
type
Standard & option 8
Nominal diameter in 6 6 8 6 6 6 6 6
Actual outside diameter mm 168,3 168,3 219,1 168,3 168,3 168,3 168,3 168,3
Options 5, 6 et 100A
Nominal diameter in 5 5 6 6 6 6 6 6
Actual outside diameter mm 141,3 141,3 168,3 168,3 168,3 168,3 168,3 168,3
Options 100C
Nominal diameter in 6 6 8 - - - - -
Actual outside diameter mm 168,3 168,3 219,1 - - - - -
Casing paint Colour code RAL 7035
4 - PHYSICAL AND ELECTRICAL DATA FOR 30XB UNITS
