4.9 - Electrical data, optional hydraulic module
The pumps that are factory-installed in these units comply with the European Ecodesign directive ErP. The additional electrical
data required
(1)
is as follows:
Motors of single and dual low-pressure pumps for 30XB units (options 116T and 116U)
No.
(2)
description
(3)
250 300 350 400 450 500
1 Nominal e󰀩ciency at full load and nominal voltage % 86,7 86,7 87,2 88,1 89,4 89,4
1 Nominal e󰀩ciency at 75% full load and nominal voltage % 87,0 87,0 86,9 88,0 88,9 88,9
1 Nominal e󰀩ciency at 50% full load and nominal voltage % 85,5 85,5 84,5 86,1 86,7 86,7
2 E󰀩ciency level - IE3
3 Year of manufacture -
This information varies depending on the manufacturer and model at
the time of incorporation. Please refer to the motor nameplates.
4
Company name or trademark, commercial registration
number and head o󰀩ce of manufacturer
- Same as above
5 Product model number - Same as above
6 Number of motor poles - 2
7-1
Nominal shaft power output at full load and nominal voltage
(400 V)
kW 2,2 2,2 3,0 4,0 5,5 5,5
7-2 Maximum input power (400V)
(4)
kW 2,54 2,54 3,44 4,54 6,15 6,15
8 Nominal input frequency Hz 50
9-1 Nominal voltage V 3*400
9-2 Maximum current drawn (400V)
(5)
A 4,2 4,2 5,5 7,4 9,7 9,7
10 Nominal speed
r/s - r/
min
48 - 2900 48 - 2900 49 - 2915 49 - 2915 49 - 2930 49 - 2930
11 product disassembly, recycling or disposal at end of life -
Disassembly using standard tools. Disposal and recycling using an
appropriate company.
12
Operating conditions for which the motor is specically
designed
I - Altitudes above sea level m < 1000
(6)
II - Ambient air temperature °C < 40
III - Maximum operating temperature °C
Please refer to the operating conditions given in this manual or in the
specic conditions given in the Carrier selection programs.
IV - Potentially explosive atmospheres - Non ATEX environment
(1) Required by regulation No. 2019/1781 concerning the application of directive 2009/125/EC on the eco-design requirements for electric motors.
(2) Item number imposed by regulation No. 2019/1781, annex I2b.
(3) Description given by regulation No. 2019/1781, annex I2b.
(4)
To obtain the maximum input power for a unit with hydraulic module, add the maximum unit input power from the electrical data table to the pump power input .
(5) To obtain the maximum unit operating current draw for a unit with hydraulic module, add the maximum unit current draw from the electrical data table to the pump
current draw.
(6) Above 1000 m, a degradation of 3% for each 500 m should be taken into consideration.
4 - PHYSICAL AND ELECTRICAL DATA FOR 30XB UNITS
