31
30XB option 254/255 250 300 350 400 450 500 600 700 750 800
Capacity control SmartVu
TM
, Electronic Expansion Valve (EXV)
Minimum capacity % 15 15 15 15 15 15 15 15 15 15
Air heat exchanger Aluminum micro-channel coils (MCHE)
Fans FLYING-BIRD 6, axial fan with rotating impeller
Standard unit
Quantity 6 6 7 8 8 9 11 12 13 13
Maximum total air ow l/s 28920 28920 33740 38560 38560 43380 53020 57840 62660 62660
Maximum rotation speed r/s 15,7 15,7 15,7 15,7 15,7 15,7 15,7 15,7 15,7 15,7
Unit + option 15LS
Maximum total air ow l/s 23580 23580 27510 31440 31440 35370 43230 47160 51090 51090
Maximum rotation speed r/s 11,7 11,7 11,7 11,7 11,7 11,7 11,7 11,7 11,7 11,7
Water heat exchanger Flooded multi-pipe type
Water volume l 58 61 61 66 70 77 79 94 98 119
Max. water-side operating pressure without hydraulic
module
kPa 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
Hydraulic module (option)
Pump, Victaulic screen lter, relief valve, water and air drain valve,
pressure sensors, expansion tank (option)
Pump
Centrifugal pump, monocell, 48,3r/s, low or high pressure (as required), single
or dual
(as required)
Expansion vessel volume inch 50 50 50 50 50 80
Max. water-side operating pressure with hydraulic module mm 400 400 400 400 400 400
Water connections without or with hydraulic module Victaulic
®
type
Standard & option 8, without option 116
Nominal diameter in 5 5 5 5 5 5 5 6 6 6
Actual outside diameter mm 141,3 141,3 141,3 141,3 141,3 141,3 141,3 168,3 168,3 168,3
Options 5, 6 et 100A
Nominal diameter in 4 4 4 4 4 4 5 5 5 5
Actual outside diameter mm 114,3 114,3 114,3 114,3 114,3 114,3 141,3 141,3 141,3 141,3
Options 100C
Nominal diameter in 5 5 5 5 5 5 6 6 6 6
Actual outside diameter mm 141,3 141,3 141,3 141,3 141,3 141,3 168,3 168,3 168,3 168,3
Options 116
Nominal diameter in 4 4 4 4 4 4 - - - -
Actual outside diameter mm 114,3 114,3 114,3 114,3 114,3 114,3 - - - -
Casing paint Colour code RAL 7035
4 - PHYSICAL AND ELECTRICAL DATA FOR 30XB UNITS
