15
Nominal power supply V-ph-Hz 400-3-50
Voltage range V 360-440
24 V, via internal transformer
Circuits A + B (one supply) A 101 113 129 135 167 185 209 227 251 269 293 334 251 251 334 334
Circuit C (separate supply) A - - - - - - - - - - - - 125 167 125 167
Circuits A + B (one supply) kW 76 85 98 102 127 140 159 172 191 204 223 255 191 191 255 255
Circuit C (separate supply) kW - - - - - - - - - - - - 96 127 96 127
0.84 0.84 0.84 0.84 0.84 0.84 0.84 0.84 0.84 0.84 0.84 0.84 0.84 0.84 0.84 0.84
Circuits A + B (one supply) A 143 159 183 191 239 263 299 323 359 383 419 478 359 359 478 478
Circuit C (separate supply) A - - - - - - - - - - - - 179 239 179 239
Circuits A + B (one supply) A 131 146 168 175 219 241 274 296 329 351 384 438 329 329 439 438
Circuit C (separate supply) A - - - - - - - - - - - - 164 219 164 219
Circuits A + B A 304 353 375 348 426 448 481 502 535 557 590 645 535 535 645 645
Circuit C A - - - - - - - - - - - - 371 426 371 426
Circuits A + B† A 259 283 305 277 356 378 411 433 466 489 521 575 - - - -
Circuit C A - - - - - - - - - - - - - - - -
* Standardised Eurovent conditions: evaporator entering/leaving water temperature 12°C/7°C, outside air temperature 35°C, evaporator fouling factor 0.18 x 10
-4
(m
2
K)/W.
** Power input, compressors and fans, at the unit operating limits (saturated suction temperature 10°C, saturated condensing temperature 65°C) and nominal voltage of
400 V (data given on the unit nameplate).
*** Maximum unit operating current at maximum unit power input and 360 V.
**** Maximum unit operating current at maximum unit power input and 400 V (values given on the unit nameplate).
† Maximum instantaneous start-up current at operating limit values (maximum operating current of the smallest compressor(s) + fan current + locked rotor current of the
largest compressor).
Fan motor electrical data: current used in the tables below:
Units at Eurovent conditions and motor ambient air temperature of 50°C at 400 V:
3.8 A, start-up current 20 A, power input 1.75 kW.
These values are those given on the motor nameplate.
Short-circuit stability current (TN system)*
CircuitsA and B A - - - - - 500 500 500 500 630/500 630/500 630/500 630/500 630/500 630/500 630/500
Circuit C A - - - - - - - - - - - - 400 400 400 400
CircuitsA and B kA - - - - - 70 70 70 70 60/70 60/70 60/70 70 70 60/70 60/70
Circuit C kA - - - - - - - - - - - - 60 60 60 60
CircuitsA and B kA/kA 9/26 9/26 9/26 9/26 9/26 13/26 13/26 13/26 13/26 15/30 15/30 15/30 13/26 13/26 15/30 15/30
Circuit C kA/kA - - - - - - - - - - - - 13/26 13/26 13/26 13/26
CircuitsA and B A 200 200 200/250 250/315† 250/315† 400 400 400 400 500 630 630 400 400 630 630
Circuit C A - - - - - - - - - - - - 400 400 400 400
Circuits A and B kA 50 50 50 50 50 50 50 50 50 50 50 50 50 50 50 50
Circuit C kA - - - - - - - - - - - - 50 50 50 50
CircuitsA and B kA - - - - - 315 315 400 400 400 630 630 400 400 630 630
Circuit C kA - - - - - - - - - - - - 250 250 250 250
Circuits A and B kA - - - - - 50 50 50 50 50 50 50 50 50 50 50
Circuit C kA - - - - - - - - - - - - 50 50 50 50
* Type of system earthing
** Icw: assigned short-time current
*** Ipk: assigned current, admissible peak
† For units with options 12 and 116 use the higher value.
†† Icc/Icf: assigned conditional short-circuit current
The short circuit current stability values given above for the TN system are also valid for IT for units 30RB 302 to 522. For units 30RB 162 to 262 and 30RB 602 to 802
modications are required.
