Section 8 - Exploded Views and Parts
Carrier Liquid-cooled 25 kW Generator
Mounting Base — Drawing No. 0E9964-E
ITEM PART NO. QTY. DESCRIPTION
1 0D9336 3 PANEL BRACKET
2 0E9939 2 CTRL PNL SUPPORT 2.5L FORD
3 0C2454 24 SCREW TH-FRM M6-1 X 16 N WA Z/JS
4 049813 1 NUT HEX M6 X 1.0 G8 YEL CHR
5 022097 1 WASHER LOCK M6-1/4
6 026850 2 WASHER SHAKEPROOF EXT 1/4 STL
7 055414 1 LUG SLDLSS #2-#8 X 17/64 CU
8 022473 1 WASHER FLAT 1/4-M6 ZINC
9 047411 1 SCREW HHC M6-1.0 X 16 G8.8
10 052860 4 NUT FLANGED HEX M12-1.75
11 052251 4 DAMPENER VIBRATION 40 BLUE
12 052257 4 SPACER .49 X .62 X 1.87 PWDR/ZNC
13 052252 4 DAMPENER VIBRATION
14 052259 4 WASHER FLAT M12
15 052891 4 SCREW HHC M12-1.75 X 80 G8.8
16 0536210261 1 ASSY WIRE #0 12.00"
17 074906 1 SCREW HHTT M6-1.0 X 20 BP
18 077483 REF BATT 12VDC 75-AH 26 (NOT SHOWN)
19 0E9941 1 HOLD DOWN BATTERY 2.5L FORD
20 025507 3 WASHER SHAKEPROOF EXT 7/16 STL
21 059980 1 SCREW HHC M10-1.5 X 25 G10.9
22 046526 1 WASHER LOCK M10
23 022131 1 WASHER FLAT 3/8-M10 ZINC
24 021991 1 EARTH STRAP
25 038805J 1 CABLE BATT BLK #1 X 30.00
26 050331 REF BATTERY POST COVER (BLACK)
27 050331A REF BATTERY POST COVER (RED)
28 038804J 1 CABLE BATT RED #1 X 40.50
29 045771 REF NUT HEX M8-1.25 G8 YEL CHR
30 022129 REF WASHER LOCK M8-5/16
31 027482 1 WASHER SHAKEPROOF EXT 5/16 STL
32 075763 1 BOOT BATTERY CABLE
33 0E9748 1 ASSY MTG BASE 2.5L FORD
34 0E9940 1 TRAY BATTERY 2.5L FORD
35 065852 1 SPRING CLIP HOLDER .37-.62
36 024469 1 SCREW HHTT #10-32 X 3/8 CZ
