21
DETAILED COOLING CAPACITIES
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh{
To tal
Sys-
tem
KW**
Capacity
MBtuh{
To tal
Sys-
tem
KW**
Capacity
MBtuh{
To tal
Sys-
tem
KW**
Capacity
MBtuh{
To tal
Sys-
tem
KW**
Capacity
MBtuh{
To tal
Sys-
tem
KW**
Capacity
MBtuh{
To tal
Sys-
tem
KW**
To tal Sens} Tota l Sens} Tot a l Sens} To ta l Sens} Tot a l Sens} Tot a l Sens}
24ABA360A30 Outdoor Section With CAP**6024A** Indoor Section
1750
72 67.65 35.66 4.15 64.56 34.48 4.58 61.30 33.25 5.06 57.89 31.98 5.58 54.20 30.63 6.15 50.10 29.15 6.77
67 62.07 43.94 4.10 59.24 42.75 4.53 56.25 41.50 5.01 53.12 40.22 5.54 49.74 38.85 6.11 46.03 37.38 6.74
62 57.01 52.17 4.06 54.45 50.95 4.49 51.79 49.66 4.97 49.04 48.27 5.50 46.34 46.34 6.08 43.50 43.50 6.72
57 55.50 55.50 4.04 53.42 53.42 4.48 51.22 51.22 4.96 48.89 48.89 5.50 46.35 46.35 6.08 43.51 43.51 6.72
2000
72 68.69 37.30 4.26 65.46 36.09 4.69 62.07 34.85 5.16 58.54 33.56 5.69 54.71 32.19 6.26 50.48 30.69 6.87
67 63.07 46.60 4.21 60.11 45.38 4.64 57.00 44.12 5.11 53.75 42.82 5.64 50.27 41.45 6.21 46.44 39.94 6.84
62 58.17 55.80 4.16 55.57 54.47 4.59 52.95 52.95 5.07 50.49 50.49 5.61 47.78 47.78 6.19 44.74 44.74 6.82
57 57.57 57.57 4.16 55.35 55.35 4.59 52.99 52.99 5.07 50.50 50.50 5.61 47.78 47.78 6.19 44.74 44.74 6.82
2250
72 69.44 38.83 4.36 66.10 37.62 4.79 62.61 36.36 5.27 58.97 35.06 5.79 55.04 33.67 6.36 50.70 32.16 6.97
67 63.79 49.12 4.31 60.73 47.89 4.74 57.53 46.62 5.21 54.20 45.31 5.74 50.63 43.90 6.31 46.72 42.34 6.93
62 59.18 59.18 4.27 56.90 56.90 4.70 54.41 54.41 5.18 51.77 51.77 5.72 48.91 48.91 6.30 45.70 45.70 6.93
57 59.25 59.25 4.27 56.90 56.90 4.70 54.42 54.42 5.18 51.78 51.78 5.72 48.91 48.91 6.30 45.70 45.70 6.93
Multipliers for Determining the Performance With Other Indoor Sections
Cooling Indoor Model Capacity Power Furnace Model
*CAP**6024A** 1.00 1.00
CAP**6021A** 0.98 0.98
CNPH*6024A** 0.99 0.99
CNPV*6024A** 0.99 0.99
CSPH*6012A** 1.00 1.00
FV4BNB006 0.99 0.97
FX4CN(B,F)060 1.01 1.01
FY4ANB060 0.98 0.98
CAP**6021A** 0.97 0.97 58CV(A,X)110---20
CSPH*6012A** 0.98 0.98 58CV(A,X)110---20
CAP**6024A** 0.98 0.98 58CV(A,X)135---22
CNPH*6024A** 0.97 0.96 58CV(A,X)135---22
CNPV*6024A** 0.97 0.97 58CV(A,X)135--- 22
CSPH*6012A** 0.98 0.97 58CV(A,X)135---22
CAP**6024A** 0.98 0.97 58CV(A,X)155---22
CNPH*6024A** 0.98 0.97 58CV(A,X)155---22
CNPV*6024A** 0.98 0.97 58CV(A,X)155--- 22
CSPH*6012A** 0.98 0.97 58CV(A,X)155---22
NOTE: When the required data fall between the published data, interpolation may be performed. Extrapolation is not an acceptable practice.
* Detailed cooling capacities are based on indoor and outdoor unit at the same elevation per ARI standard 210/240---94. If additional tubing length and/or
indoor unit is located above outdoor unit, a slight variation in capacity may occur.
** Total system kW is total of indoor and outdoor unit kilowatts.
{ Total and sensible capacities are net capacities. Blower motor heat has been subtracted.
} Sensible capacities shown are based on 80˚F(27˚C) entering air a t the indoor coil. For sensible capacities at other than 80˚F(27˚C), deduct 835 Btuh
(245 kW) per 1000 CFM (480 L/S) of indoor coil air for each degree below 80˚F(27˚C), or add 835 Btuh (245 kW) per 1000 CFM (480 L/S) of indoor coil air
per degree above 80˚F(27˚C).
When the required data fall between the published data, interpolation may be performed.
24ABA3
