Carrier Base 24ABA3 User Manual

4
ACCESSORY THERMOSTATS
THERMOSTAT / SUBBASE PKG. DESCRIPTION
TSTATCCPRH01---B Thermidistat Control --- Programmable / Non ---Programmable Thermostat with Humidity control
TSTATCCPAC01---B T h e r m o s t a t --- A u t o C h a n g e o v e r, 7 --- D a y P r o g r a m m a b l e , _F/_C , 1 --- S t a g e H e a t , 1 --- S t a g e C o o l
TSTATCCNAC01---C T h e r m o s t a t --- A u t o C h a n g e o v e r, N o n --- P r o g r a m m a b l e , _F/_C , 1 --- S t a g e H e a t , 1 --- S t a g e C o o l
TSTATCCBAC01--- B Builder’s Thermostat --- Manual Changeover, Non---Programmable, _F/_C , 1 --- S t a g e H e a t , 1 --- S t a g e C o o l
TSTATCC SEN01--- B Outdoor Air Temperature Sensor
TSTATXXBBP01 Backplate for Builder’s Thermostat
TSTATXXNBP01 Backplate for Non ---Programmable Thermostat
TSTATXXPBP01 Backplate for Programmable Thermostat
TSTATXXCNV10 Thermostat Conversion Kit (4 to 5 wires) --- 10 Pack
ACCESSORIES
KIT NUMBER DESCRIPTION
Size --- Voltage & Series
18--- 30 24--- 30 30 --- 30 36--- 30 42--- 30 48 --- 30 60 --- 30
KAAFT0101AAA FREEZE THERMOSTAT X X X X X X X
KAATD0101TDR TIME DELAY RELAY X X X X X X X
KAAWS0101AAA WINTER START X X X X X X X
KSALA0301410 LOW AMBIENT PSW X X X X X X X
KSALA0601AAA MOTORMASTER 230V X X X X X X X
KSALA0701AAA MOTORMASTER 460V
HC32GE234 MOTOR FAN BALL BEARING X
HC34GE239 MOTOR FAN BALL BEARING X X
HC40GE226 MOTOR FAN BALL BEARING X X
HC38GE219 MOTOR FAN BALL BEARING X
HC40GE228 MOTOR FAN BALL BEARING X
KSAHS1701AAA HARD START (CAP / RELAY) X X X X X X X
KSACY0101AAA CYCLE PROTECTOR X X X X X X X
KSASF0101AAA SUPPORT FEET X X X X X X X
KAACS0201PTC START ASSIST PTC X X X X X X X
KAACH1201AAA CRANKCASE HTR X X X
KAACH1401AAA CRANKCASE HTR X X X X
KAACH1501AAA CRANKCASE HTR
KSATX0201PUR TXV PURON HSO X X X
KSATX0301PUR TXV PURON HSO X X
KSATX0401PUR TXV PURON HSO X
KSATX0501PUR TXV PURON HSO X
KSASH0601COP SOUND HOOD X X X X X X
KSASH2101COP SOUND HOOD X
KAALP0301PUR LOW PRE S SURE SWITCH X X X X X X X
KAAHI0401PUR HIGH PRESSURE SWITCH X X X X X X X
ACCESSORY USAGE GUIDELINE
ACCESSORY
REQUIRED FOR LOW ---AMBIENT
COOLING APPLICATIONS (Below 55°
F)
REQUIRED FOR
LONG LINE
APPLICATIONS*
(Over 80 Ft.)
REQUIRED FOR
SEA COAST
APPLICATIONS
(Within 2 miles)
Crankcase Heater Yes Yes No
Evaporator Freeze Thermostat Yes No No
Accumulator No No No
Compressor Start Assist Capacitor and Relay Yes Yes No
Motor Master
®
Control or Low---ambient
Pressure Switch
Yes No No
Support Feet Recommended No Recommended
Liquid Line Solenoid Valve No
S e e L o n g --- L i n e A p -
plication Guideline
No
Ball Bearing Fan Motor Yes{ No No
* For tubing line sets between 80 and 200 ft. and/or 20 ft. vertical differntial, refer to Residential Split--- System Longline Application Guideline.
{ Required for Low---Ambient Controller (full modulation feature) and MotorMasterr Control only.
Accessory Description and Usage (Listed Alphabetically)
24ABA3

Carrier Base 24ABA3 Specifications

Operating Environment

suction temperature	F
wet bulb temperature	F
dry bulb temperature	F

Power

nominal voltage	v, single phase, 60 hz
voltage limits	v to v
control circuit voltage	24v

Refrigeration Components

refrigerant type	Puronr (R-410A)
high-pressure switch	included
low pressure switch	included

Weight and Dimensions

nominal tons	1-1/2 to 5 tons
