Carrier Base 24ABA3 User Manual

9
COMBINATION RATINGS CONTINUED
Unit Size ---
Voltage &
Series
Indoor
Model
To t a l
Cap. BTUH
Factory
Supplied
Enhancement
SEER
EER
Furnace
Model
Standard
Rating
TDR{
24---30
*CAP**2414A** 23,000 TXV 13.00 11.00
CAP**2414A** 22,600 TDR&TXV 14.00 11.50 58CV(A,X)070---12
CAP**2417A** 22,800 TXV 13.00 11.00
CAP**2417A** 22,600 TDR&TXV 14.00 11.50 58MVB060---14
CAP**2417A** 22,600 TDR&TXV 14.00 11.70 58CV(A,X)090---16
CAP**3014A** 23,000 TXV 13.00 11.00
CAP**3014A** 22,800 TDR&TXV 14.00 11.50 58CV(A,X)070---12
CAP**3017A** 23,000 TXV 13.00 11.00
CAP**3017A** 22,800 TDR&TXV 14.00 11.70 58MVB060---14
CAP**3017A** 22,800 TDR&TXV 14.00 11.70 58CV(A,X)090---16
CNPV*2414A** 22,800 TXV 13.00 11.00
CNPV*2414A** 22,600 TDR&TXV 14.00 11.50 58CV(A,X)070---12
CNPV*2417A** 22,800 TXV 13.00 11.00
CNPV*2417A** 22,600 TDR&TXV 14.00 11.50 58MVB060---14
CNPV*2417A** 22,600 TDR&TXV 14.00 11.50 58CV(A,X)090---16
CNPV*3014A** 23,000 TXV 13.00 11.00
CNPV*3014A** 22,800 TDR&TXV 14.00 11.15 58CV(A,X)070---12
CNPV*3017A** 23,000 TXV 13.00 11.00
CNPV*3017A** 22,800 TDR&TXV 14.00 11.70 58MVB060---14
CNPV*3017A** 22,800 TDR&TXV 14.00 11.70 58CV(A,X)090---16
CNPH*2417A** 22,800 TXV 13.00 11.00
CNPH*2417A** 22,600 TDR&TXV 14.00 11.50 58MVB040---14
CNPH*2417A** 22,600 TDR&TXV 14.00 11.50 58CV(A,X)070---12
CNPH*3017A** 23,000 TXV 13.00 11.00
CNPH*3017A** 22,800 TDR&TXV 14.00 11.70 58MVB040---14
CNPH*3017A** 22,800 TDR&TXV 14.00 11.70 58CV(A,X)070---12
CNPF*2418A** 22,800 TXV 13.00 11.00
CSPH*2412A** 23,000 TXV 13.00 11.00
CSPH*2412A** 22,600 TDR&TXV 14.00 11.50 58MVB040---14
CSPH*2412A** 22,800 TDR&TXV 14.00 11.50 58MVB060---14
CSPH*2412A** 22,800 TDR&TXV 14.00 11.50 58CV(A,X)070---12
CSPH*2412A** 22,800 TDR&TXV 14.00 11.70 58CV(A,X)090---16
CSPH*2412A** 22,800 TDR&TXV 14.00 11.50 58CV(A,X)110---20
CSPH*2412A** 22,800 TDR&TXV 14.00 11.50 58CV(A,X)135---22
CSPH*3012A** 23,000 TXV 13.00 11.00
CSPH*3012A** 22,800 TDR&TXV 14.00 11.70 58MVB040---14
CSPH*3012A** 22,800 TDR&TXV 14.00 11.70 58MVB060---14
CSPH*3012A** 22,800 TDR&TXV 14.00 11.70 58MVB080---14
See notes on pg. 14
24ABA3

Carrier Base 24ABA3 Specifications

Operating Environment

suction temperature	F
wet bulb temperature	F
dry bulb temperature	F

Power

nominal voltage	v, single phase, 60 hz
voltage limits	v to v
control circuit voltage	24v

Refrigeration Components

refrigerant type	Puronr (R-410A)
high-pressure switch	included
low pressure switch	included

Weight and Dimensions

nominal tons	1-1/2 to 5 tons
