13. Winter Start Control
This control is designed to alleviate nuisance opening of the
low--pressure switch by bypassing it for the first 3 minutes of
operation.
ELECTRICAL DATA
UNIT
SIZE
V/PH
OPER
VOLTS*
COMPR FAN
MCA
MIN WIRE
SIZE{
MIN WIRE
SIZE{
MAX
LENGTH
(FT)}
MAX
LENGTH
(FT)}
MAX
FUSE**
or CKT
BRK
AMPS
MAX MIN LRA RLA FLA 60° C 75° C 60° C 75° C
18
208/230/1 253 197
48.0 9.0 0.5 11.7 14 14 67 64 15
24 58.3 13.5 0.75 17.6 14 14 45 43 25
30 64.0 12.8 0.75 16.8 14 14 47 45 25
36 77.0 14.1 1.4 19.0 12 12 66 63 30
42 112.0 17.9 1.1 23.5 12 12 53 51 40
48 109.0 19.9 1.4 26.2 10 10 76 73 40
60 134.0 26.4 1.2 34.2 8 8 91 86 50
* Permissible limits of the voltage range at which the unit will operate satisfactorily
{ If wire is applied at ambient greater than 30˚ C(86˚ F), consult table 310 ---16 of the NEC (ANSI/NFPA 70). The ampacity of non ---metallic---sheathed cable
(NM), trade name ROMEX, shall be that of 60˚ C (140˚ F) conditions, per the NEC (ANSI/NFPA 70) Article 336---26. If other than uncoated (no---plated), 60
or 75˚ C (140 or 167˚ C) insulation, copper wire (solid wire for 10 AWG or smaller, stranded wire for larger than 10 AWG) is used, consult applicable tables
of the NEC (ANSI/ NFPA 70).
} Length shown is as measured 1 way along wire path between unit and service panel for voltage drop not to exceed 2%.
** Time---Delay fuse.
FLA --- F u l l L o a d A m ps
LRA --- L o c k e d R o t o r A m ps
MCA --- Minimum Circuit Amps
RLA ---RatedLoadAmps
NOTE: Control circuit is 24---V on all units and requires external power source. Copper wire must be used from service disconnect to unit.
All motors/compressors contain internal overload protection.
A--WEIGHTED SOUND POWER (DBA)
UNIT
SIZE
STANDARD
RATING
TYPICAL OCTAVE BAND SPECTRUM (without tone adjustment)
125 250 500 1000 2000 4000 8000
18 76 52.0 61.0 67.0 70.5 67.5 63.5 56.5
24 76 56.5 64.0 67.5 69.5 67.0 65.0 60.5
30 76 55.0 63.5 69.0 72.0 69.0 64.5 59.5
36 76 58.5 64.0 68.0 69.5 66.0 62.5 55.0
42 78 57.5 65.0 71.0 73.0 70.5 67.5 62.5
48 78 59.5 67.0 72.5 73.0 70.0 67.0 62.5
60 78 53.5 61.0 67.5 74.5 68.5 62.5 61.0
A --WEIGHTED SOUND POWER (DBA) WITH ACCESSORY SOUND HOOD
UNIT
SIZE
STANDARD
RATING
TYPICAL OCTAVE BAND SPECTRUM (without tone adjustment)
125 250 500 1000 2000 4000 8000
18 74 50.0 61.5 64.5 66.5 64.0 61.0 54.5
24 75 58.0 65.5 69.0 70.5 68.0 65.0 59.0
30 76 56.5 64.0 69.5 71.5 69.0 64.5 58.0
36 76 58.5 64.5 68.5 69.5 67.0 63.5 58.5
42 77 57.5 65.0 70.5 72.0 70.0 67.0 62.0
48 77 59.5 67.0 72.0 72.0 69.5 66.5 62.0
60 77 53.0 61.0 66.5 73.0 66.0 60.5 57.5
CHARGING SUBCOOLING (TXV--TYPE EXPANSION DEVICE)
UNIT SIZE--- VOLTAGE & SERIES REQUIRED SUBCOOLING (_F)
18---30 8
24---30 13
30---30 16
36---30 16
42---30 10
48---30 17
60---30 11
24ABA324ABA3

Carrier Base 24ABA3 Specifications

Operating Environment

suction temperature	F
wet bulb temperature	F
dry bulb temperature	F

Power

nominal voltage	v, single phase, 60 hz
voltage limits	v to v
control circuit voltage	24v

Refrigeration Components

refrigerant type	Puronr (R-410A)
high-pressure switch	included
low pressure switch	included

Weight and Dimensions

nominal tons	1-1/2 to 5 tons
