COMBINATION RATINGS CONTINUED
Unit Size ---
Voltage &
Series
Indoor
Model
To t a l C ap .
BTUH
Factory
Supplied
Enhancement
SEER
EER
Furnace
Model
Standard
Rating
TDR{
24---30
CSPH*3012A** 22,800 TDR&TXV 14.00 11.70 58MVB080---20
CSPH*3012A** 22,800 TDR&TXV 14.00 11.70 58MVB100---20
CSPH*3012A** 22,800 TDR&TXV 14.00 11.70 58MVB120---20
CSPH*3012A** 22,800 TDR&TXV 14.00 11.70 58CV(A,X)070---12
CSPH*3012A** 22,800 TDR&TXV 14.00 11.70 58CV(A,X)090---16
CSPH*3012A** 22,800 TDR&TXV 14.00 11.70 58CV(A,X)110---20
CSPH*3012A** 22,800 TDR&TXV 14.00 11.70 58CV(A,X)135---22
CSPH*3012A** 22,800 TDR&TXV 14.00 11.70 58CV(A,X)155---22
FY4ANF024 22,600 TDR&TXV 13.00 11.00
FY4ANF030 22,800 TDR&TXV 13.20 11.00
FX4CNF024 23,000 TDR&TXV 14.00 11.50
FX4CNF030 23,200 TDR&TXV 14.00 11.50
FF1ENP024 22,600 TDR&TXV 13.00 11.00
FF1ENP030 22,600 TDR&TXV 13.00 11.00
FV4BNF002 23,000 TDR&TXV 14.00 11.70
FV4BNF003 23,000 TDR&TXV 14.00 12.00
30---30
*CAP**3014A** 28,000 TXV 13.00 11.00
CAP**3014A** 27,600 TDR&TXV 13.50 11.20 58CV(A,X)070---12
CAP**3017A** 28,000 TXV 13.00 11.00
CAP**3017A** 27,600 TDR&TXV 14.00 11.50 58MVB060---14
CAP**3017A** 27,600 TDR&TXV 14.00 11.50 58CV(A,X)090---16
CAP**3614A** 27,000 TXV 13.00 11.00
CAP**3614A** 26,600 TDR&TXV 14.00 11.50 58CV(A,X)070---12
CAP**3617A** 28,000 TXV 13.00 11.00
CAP**3617A** 27,600 TDR&TXV 14.00 11.50 58MVB060---14
CAP**3617A** 27,800 TDR&TXV 14.00 11.50 58CV(A,X)090---16
CAP**3621A** 28,000 TXV 13.00 11.00
CAP**3621A** 27,800 TDR&TXV 14.00 11.50 58MVB080---14
CAP**3621A** 27,800 TDR&TXV 14.00 11.50 58CV(A,X)110---20
CNPV*3014A** 28,000 TXV 13.00 11.00
CNPV*3014A** 27,600 TDR&TXV 13.50 11.20 58CV(A ,X)070---12
CNPV*3017A** 28,000 TXV 13.00 11.00
CNPV*3017A** 27,600 TDR&TXV 14.00 11.50 58MVB060---14
CNPV*3017A** 27,600 TDR&TXV 14.00 11.50 58CV(A ,X)090---16
CNPV*3617A** 28,000 TXV 13.00 11.00
CNPV*3617A** 27,600 TDR&TXV 14.00 11.50 58MVB060---14
CNPV*3617A** 27,600 TDR&TXV 14.00 11.50 58CV(A ,X)090---16
CNPV*3621A** 28,000 TXV 13.00 11.00
CNPV*3621A** 27,600 TDR&TXV 14.00 11.50 58MVB080---14
CNPV*3621A** 27,800 TDR&TXV 14.00 11.50 58CV(A ,X)110---20
CNPH*3017A** 28,000 TXV 13.00 11.00
CNPH*3017A** 27,600 TDR&TXV 13.50 11.20 58MVB040---14
CNPH*3017A** 27,600 TDR&TXV 14.00 11.50 58CV(A,X)070---12
CNPH*3617A** 28,000 TXV 13.00 11.00
CNPH*3617A** 27,600 TDR&TXV 13.50 11.20 58MVB040---14
CNPH*3617A** 27,600 TDR&TXV 14.00 11.50 58CV(A,X)070---12
See notes on pg. 14
24ABA3

Carrier Base 24ABA3 Specifications

Operating Environment

suction temperature	F
wet bulb temperature	F
dry bulb temperature	F

Power

nominal voltage	v, single phase, 60 hz
voltage limits	v to v
control circuit voltage	24v

Refrigeration Components

refrigerant type	Puronr (R-410A)
high-pressure switch	included
low pressure switch	included

Weight and Dimensions

nominal tons	1-1/2 to 5 tons
