11
COMBINATION RATINGS CONTINUED
Unit Size ---
Voltage &
Series
Indoor
Model
To t a l C ap .
BTUH
Factory
Supplied
Enhancement
SEER
EER
Furnace
Model
Standard
Rating
TDR{
30---30
CNPF*3618A** 28,000 TXV 13.00 11.00
CSPH*3012A** 28,000 TXV 13.00 11.00
CSPH*3012A** 27,600 TDR&TXV 13.50 11.20 58MVB040---14
CSPH*3012A** 27,600 TDR&TXV 14.00 11.50 58CV(A,X)070---12
CSPH*3612A** 28,000 TXV 13.20 11.00
CSPH*3612A** 27,600 TDR&TXV 14.00 11.50 58MVB040---14
CSPH*3612A** 27,600 TDR&TXV 14.00 11.50 58CV(A,X)070---12
FY4ANF030 27,600 TDR&TXV 13.00 11.00
FY4ANF036 27,800 TDR&TXV 13.00 11.00
FX4CNF030 28,000 TDR&TXV 13.50 11.20
FX4CN(B,F)036 28,200 TDR&TXV 14.00 11.50
FF1ENP030 27,400 TDR&TXV 13.00 11.00
FF1ENP036 28,000 TDR&TXV 13.20 11.00
FV4BNF002 27,800 TDR&TXV 14.00 11.50
FV4BNF003 28,000 TDR&TXV 14.00 11.70
FV4BNF005 28,800 TDR&TXV 14.00 12.00
36---30
*CAP**3617A** 34,000 TXV 13.00 11.00
CAP**3614A** 33,000 TXV 13.00 11.00
CAP**3614A** 32,600 TDR&TXV 13.50 11.20 58CV(A,X)070---12
CAP**3617A** 33,600 TDR&TXV 14.00 11.50 58MVB060---14
CAP**3617A** 33,600 TDR&TXV 14.00 11.50 58CV(A,X)090---16
CAP**3621A** 34,000 TXV 13.00 11.00
CAP**3621A** 33,600 TDR&TXV 13.50 11.20 58MVB080---14
CAP**3621A** 33,800 TDR&TXV 14.00 11.50 58CV(A,X)110---20
CAP**4221A** 34,000 TXV 13.00 11.00
CAP**4221A** 33,800 TDR&TXV 14.00 11.50 58MVB080---14
CAP**4221A** 34,000 TDR&TXV 14.00 11.50 58CV(A,X)110---20
CAP**4224A** 34,000 TXV 13.00 11.00
CAP**4224A** 33,800 TDR&TXV 14.00 11.50 58MVB040---14
CAP**4224A** 34,000 TDR&TXV 14.00 11.70 58CV(A,X)135---22
CNPV*3617A** 34,000 TXV 13.00 11.00
CNPV*3617A** 33,400 TDR&TXV 13.50 11.20 58MVB060---14
CNPV*3617A** 33,600 TDR&TXV 14.00 11.50 58CV(A ,X)090---16
CNPV*3621A** 34,000 TXV 13.00 11.00
CNPV*3621A** 33,600 TDR&TXV 13.00 11.00 58MVB080---14
CNPV*3621A** 33,800 TDR&TXV 13.50 11.20 58CV(A ,X)110---20
CNPV*4221A** 34,000 TXV 13.00 11.00
CNPV*4221A** 33,800 TDR&TXV 14.00 11.50 58MVB080---14
CNPV*4221A** 34,000 TDR&TXV 14.00 11.70 58CV(A ,X)110---20
CNPH*3617A** 34,000 TXV 13.00 11.00
CNPH*3617A** 33,400 TDR&TXV 13.50 11.20 58MVB040---14
CNPH*3617A** 33,400 TDR&TXV 13.50 11.20 58CV(A,X)070---12
CNPH*4221A** 34,000 TXV 13.00 11.00
See notes on pg. 14
24ABA3

Carrier Base 24ABA3 Specifications

Operating Environment

suction temperature	F
wet bulb temperature	F
dry bulb temperature	F

Power

nominal voltage	v, single phase, 60 hz
voltage limits	v to v
control circuit voltage	24v

Refrigeration Components

refrigerant type	Puronr (R-410A)
high-pressure switch	included
low pressure switch	included

Weight and Dimensions

nominal tons	1-1/2 to 5 tons
