( ) 16
USE OF REMOTE CONTROL (Cont.)
↕ Swing Up and Down Function
To automatically ↕ Swing the horizontal louvers for the vertical supply
air direction ( Up- Down )
Perform this function while the air conditioner is in operation.
• Press ↕ Swing button on the remote control more than 2 seconds,
the louver will swing up and down automatically.
• Adjust the horizontal louvers automatically
Press ↕ Swing button on the remote control less than 2 seconds,
Used to stop or start horizontal louver movement or set the desired
up/down air flow direction. The louver changes 6 degree in angle for
each press
• To stop the function, press ↕ Swing button again.
To set the horizontal supply air direction (left - right)
• To set the horizontal air flow direction ( left - right ) move
the deflector rod manually to adjust the air flow in the
direction you prefer.
• Adjust the vertical louvers manually using the lever on the
vertical louver arm.
• Take care not to catch fingers on the fan, horizontal louver
or to damage vertical louvers.
When the air conditioner is in operation and the horizontal
louver is in a specific position, move the lever of vertical
louvers to right or left to adjust horizontal supply air.
Range
Deflector rod
For vertical Louver
