DLFSOAH: Installation Instructions
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
3
ACCESSORIES
The system is shipped with the following accessories (see Table 1). Use all of the installation parts and accessories to install the system. Improper installation
may result in water leakage, electrical shock and fire, or cause the equipment to fail.
Keep the installation manual in a safe place and do not discard any other accessories until the installation work has been completed.
Table 1 — Accessories
Table 2 — Accessories (Pipe)
NAME SHAPE QUANTITY
Cable Tie 6
Drainpipe Adapter 1
Screw kits
1
(8,8,2,2,3)
Tubing Cover 1
Remote Controller 1
Wire Controller (optional) 1
Rubber Grommet 1
Wi-Fi Dongle (optional) 1
Panel 1
Brass Nut 2
NAME SHAPE QUANTITY (PC)
Connecting
Pipe Assembly
Liquid Side 1/4in (Φ 6.35)
These parts must be purchased separately.
Consult the dealer about the proper pipe size of
the unit purchased.
Gas Side
3/8in (Φ 9.52)
1/2in (Φ12.7)
