FMC4X, FMC4Z: Installation Instructions
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
6
- Shaded boxes represent airflow outside the required 300-450 cfm/ton.
NOTES:
1. Airflow data is without filter or electric heat accessory. Heater adds 0.05-in. static.
2. Use dry coil data for determining electric heater airflow.
3. Use wet coil data for determining cooling airflow.
Accessory louver panel adds 0.05-in. Static.
Table 3 – Airflow Performance (CFM) — Use for Selecting Heat Pump Speed of PSC Motor (Cased, Back Return)
Model
Motor
Speed
CFM Wet Coil w ithout Filter or Electric Heat, Cased, Back Return
External Static Pressure-Inches W.C.[kPa]
0 [0] 0.05 [.0125] 0.1 [.025] 0.15 [.0375] 0.2 [.050] 0.25 [.0625] 0.3 [.075] 0.35 [.0875]
18K
L
714 679 636 585 527 461 387 306
M
829 790 743 690 628 559 483 399
H
876 830 776 723 662 593 517 432
24K
L 714 679 636
585 527 461 387 306
M 829 790 743 690 628
559 483 399
H 876 830 776 723 662
593 517 432
Model
Motor
Speed
CFM Wet Coil w ithout Filter or Electric Heat, Cased, Back Return
External Static Pressure-Inches W.C.[kPa]
0 [0] 0.1 [.025] 0.15 [.0375] 0.2 [.050] 0.3 [.075] 0.4 [.100] 0.5 [.125] 0.6 [.150]
30K
L
1191 1096 1047 997 894 787 675 560
M
1299 1201 1151 1101 1000 897 793 687
H
1435 1323 1268 1214 1107 1003 902 804
36K
L 1191 1096 1047 997
894 787 675 560
M 1299 1201 1151 1101 1000
897 793 687
H
1435 1323 1268 1214 1107 1003 902 804
Table 4 – Airflow Performance (CFM) — Use for Selecting Heat Pump Speed of PSC Motor (Cased, Bottom Return)
Model
Motor
Speed
CFM Wet Coil w ithout Filter or Electric Heat, Cased, Bottom Return
External Static Pressure-Inches W.C.[kPa]
0 [0] 0.05 [.0125] 0.1 [.025] 0.15 [.0375] 0.2 [.050] 0.25 [.0625] 0.3 [.075] 0.35 [.0875]
18K L
726 689 645 593 531 464 392 315
M
845 801 753 692 627 559 487 411
H
887 832 773 711 644 573 498 419
24K L 726 689 645
593 531 464 392 315
M 845 801 753 692 627
559 487 411
H 887 832 773 711 644
573 498 419
Model
Motor
Speed
CFM Wet Coil w ithout Filter or Electric Heat, Cased, Bottom Return
External Static Pressure-Inches W.C.[kPa]
0 [0] 0.1 [.025] 0.15 [.0375] 0.2 [.050] 0.3 [.075] 0.4 [.100] 0.5 [.125] 0.6 [.150]
30K L
1200 1095 1042 989 880 768 655 539
M
1305 1208 1158 1106 998 884 764 638
H
1423 1327 1276 1224 1113 994 867 733
36K L 1200 1095 1042 989
880 768 655 539
M 1305 1208 1158 1106 998
884 764 638
H
1423 1327 1276 1224 1113 994 867 733
