FMC4X, FMC4Z: Installation Instructions
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
7
- Shaded boxes represent airflow outside the required 300-450 cfm/ton.
NOTES:
1. Airflow data is without filter or electric heat accessory. Heater adds 0.05-in. static.
2. Use dry coil data for determining electric heater airflow.
3. Use wet coil data for determining cooling airflow.
Accessory louver panel adds 0.05-in. Static.
Table 5 – Airflow Performance (CFM) — Use for Selecting Heat Pump Speed of ECM Motor (Cased, Back Return)
Model
Motor
Speed
CFM Wet Coil w ithout Filter or Electric Heat, Cased, Back Return
External Static Pressure-Inches W.C.[kPa]
0 [0] 0.1 [.025] 0.15 [.0375] 0.2 [.050] 0.3 [.075] 0.4 [.100] 0.5 [.125] 0.55 [.1375]
18K
1
753 655 609 564 481 407 340 309
2
913 828 787 746 666 588 513 476
3
1044 982 945 904 810 700 575 500
4
1153 1058 1007 953 837 711 578 503
5
1163 1068 1017 963 847 719 580 506
24K
1 753 655 609
564 481 407 340 309
2
913 828 787 746 666 588 513 476
3
1044 982 945 904 810 700 575 500
4
1153 1058 1007 953 837 711 578 503
5
1163 1068 1017 963 847 719 580 506
30K
1 801
700 651 602 508 418 331 288
2 1015 916 869 822
731 645 562 523
3
1177 1107 1069 1029 943 848 745 670
4
1327 1279 1245 1203 1098 963 795 692
5
1493 1404 1350 1289 1150 987 798 695
36K
1
801 700 651 602 508 418 331 288
2 1015 916
869 822 731 645 562 523
3 1177 1107 1069 1029 943
848 745 670
4 1327 1279 1245 1203 1098 963
795 692
5
1493 1404 1350 1289 1150 987 798 695
