Carrier HDB - General Information, Use, and Operation; Selecting Operating Mode; Changing Desired Temperature; Setting Fan Mode

GB - 2
HDB - Carrier Room Controller 2
Aspect and display
 Off
 Desired temperature / room temperature
 Set-point setting indicator
Louver position
 Fan speed
 Bar-graph (appears at power-up only)
Automatic mode
Operating mode (Cooling and Heating)
Dry mode
A = Display
C = Key for selecting the operating mode
D = Key for increasing temperature/changing louver setting
E = Button for selecting the fan speed/ louver mode selection
F = Key for decreasing temperature/changing louver setting
S = Room temperature sensor
V = Back panel fixing screws
A D
E S
F
V
C
V

 



