High Wall Type
Owner’s Manual
–16–
EN
Automatic operation
(Auto changeover)
This model is not equipped with the Automatic
Operation feature.
If Auto changeover control is selected with the
mode selection button, “A” appears on the remote
controller display. However, the alarm tone sounds
twice from the air conditioner unit and the Timer
(green) and Preheat/Defrost (orange) indications
blink alternately on the Display panel to tell the
Automatic Operation is not available.
Timer operation
Use the wired remote control for timer setting if it is
also in use.
ON timer and OFF timer
Setting TIMER
1 ON/OFF TIMER button ( or )
Press the ON or OFF TIMER buttons as required.
• The previous timer setting is displayed and flashes
along with ON/OFF timer display.
Set the timer to the desired time.
Each press of the TIMER button changes the time in
ten minute steps.
Pressing the TIMER button continually changes the
time in one hour step.
2 SET button
Press the SET button to set the timer.
The timer is indicated and the timer starts.
Cancelling TIMER
3 CLR button
Press the CLR button to cancel the timer setting.
CAUTION
• When the timer operation is selected, the
remote control automatically transmits the timer
signal to the indoor unit at the specified time.
Therefore, keep the remote control in a location
where it can transmit the signal to the indoor
unit properly. Otherwise, the time lag of up to
15minutes will occur.
• If you do not press the SET button within 30
seconds after setting the time, the setting will
be cancelled.
Once the timer operation mode is selected, the
settings are saved in the remote control.
The air conditioner will start operating under the
same conditions when the ON/OFF button of the
remote control is pressed.
If the clock display is flashing, the timer cannot be
set.
Follow the instructions in the section “SETTING
THE CLOCK” and then set the timer.
CLR
SLEEP
SET
TEMP
1
ON
OFF
SET
SET
CLR
CLR
SET
16-EN
