12
PERFORMANCE DATA
024 Coolin g Extended Performance Table
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM / BF EWB
Capacity MBtuh
To t a l
Sys
KW
Capacity MBtuh
To t a l
Sys
KW
Capacity MBtuh
To t a l
Sys
KW
Capacity MBtuh
To t a l
Sys
KW
Capacity MBtuh
To t a l
Sys
KW
Capacity MBtuh
To t a l
Sys
KW
To t a l Sens To ta l Sens To ta l Sens To ta l Sens To ta l Sens To ta l Sens
700 / 0.08
57 23.20 23.20 1.51 21.79 21.79 1.69 20.35 20.35 1.90 18.87 18.87 2.12 17.34 17.34 2.36 15.72 15.72 2.63
62 23.89 22.10 1.51 22.26 20.78 1.69 20.63 19.47 1.90 18.99 18.11 2.12 17.35 17.35 2.36 15.72 15.72 2.63
63* 24.22 17.97 1.51 22.54 16.83 1.69 20.86 15.71 1.90 19.15 14.59 2.12 17.40 13.47 2.36 15.56 12.33 2.63
67 26.13 18.68 1.51 24.33 17.52 1.69 22.51 16.37 1.90 20.66 15.25 2.12 18.76 14.06 2.37 16.75 12.87 2.63
72 28.61 15.23 1.51 26.64 14.20 1.70 24.63 13.18 1.90 22.59 12.15 2.13 20.48 11.12 2.37 18.24 10.05 2.63
800 / 0.09
57 24.24 24.24 1.53 22.73 22.73 1.71 21.20 21.20 1.91 19.62 19.62 2.14 18.00 18.00 2.38 16.26 16.26 2.64
62 24.56 23.69 1.53 22.89 22.23 1.71 21.22 21.22 1.91 19.62 19.62 2.14 18.00 18.00 2.38 16.26 16.26 2.64
63* 24.83 19.13 1.53 23.09 17.95 1.71 21.33 16.77 1.91 19.55 15.59 2.14 17.72 14.39 2.38 15.82 13.15 2.64
67 26.77 19.94 1.53 24.90 18.72 1.71 23.00 17.50 1.92 21.07 16.28 2.14 19.09 15.05 2.38 17.00 13.78 2.65
72 29.30 16.01 1.53 27.24 14.94 1.72 25.15 13.87 1.92 23.02 12.79 2.14 21.99 12.21 2.11 18.49 10.58 2.65
900 / 0.10
57 25.13 25.13 1.54 23.54 23.54 1.73 21.92 21.92 1.93 20.26 20.26 2.16 18.53 18.53 2.40 16.69 16.69 2.66
62 25.17 25.17 1.54 23.54 23.54 1.73 21.92 21.92 1.93 20.26 20.26 2.16 18.53 18.53 2.40 16.70 16.70 2.66
63* 25.31 20.26 1.54 23.51 19.02 1.73 21.70 17.77 1.93 19.86 16.52 2.16 17.98 15.25 2.40 16.03 13.93 2.66
67 27.29 21.14 1.55 25.34 19.86 1.73 23.38 18.58 1.93 21.38 17.30 2.16 19.34 15.99 2.40 17.19 14.61 2.66
72 29.85 16.75 1.55 27.72 15.64 1.73 25.55 14.52 1.94 23.35 13.40 2.16 22.34 12.76 2.13 18.67 11.09 2.66
*At 75_F (23.9 _C) entering dry bulb—Tennessee Valley Authority [TVA] rating conditions; all others at 80_F (26.7 _C) entering dry bulb. See Legend and Notes.
024 Heating Extended Performance Table --10--60 (--23.3--15.6_C)
INDOOR AIR
OUTDOOR CO I L ENTERING AIR TEMPERATURES deg F
--- 1 0 0 10 20 30 40 50 60
EDB CFM
Capacity
MBtuh
Tot a l
Sys
KW
Capacity
MBtuh
Tot a l
Sys
KW
Capacity
MBtuh
Tot a l
Sys
KW
Capacity
MBtuh
Tot a l
Sys
KW
Capacity
MBtuh
Tot a l
Sys
KW
Capacity
MBtuh
Tot a l
Sys
KW
Capacity
MBtuh
Tot a l
Sys
KW
Capacity
MBtuh
Tot a l
Sys
KW
Tot a l Integ Tot a l Integ To t a l Integ To tal Integ Total Integ Tot a l Integ To ta l Integ
Tot a l Integ
65
700 7.36 6.77 1.58 9.63 8.86 1.63 12.04 11.05 1.68 14.61 13.25 1.74 17.53 15.36 1.81 20.88 20.88 1.90 24.68 24.68 2.02 29.14 29.14 2.15
800 7.48 6.88 1.58 9.76 8.98 1.62 12.18 11.18 1.67 14.77 13.40 1.72 17.76 15.56 1.78 21.18 21.18 1.86 25.22 25.22 1.96 29.17 29.17 2.09
900 7.58 6.97 1.59 9.86 9.07 1.62 12.30 11.29 1.66 14.92 13.53 1.70 17.99 15.76 1.76 21.51 21.51 1.84 25.23 25.23 1.93 28.82 28.82 2.06
70
700 7.07 6.50 1.66 9.38 8.63 1.71 11.80 10.83 1.77 14.39 13.05 1.83 17.25 15.12 1.91 20.57 20.57 2.00 24.27 24.27 2.12 28.75 28.75 2.27
800 7.18 6.61 1.66 9.50 8.75 1.71 11.94 10.96 1.76 14.55 13.20 1.81 17.47 15.31 1.88 20.85 20.85 1.96 24.78 24.78 2.07 28.90 28.90 2.19
900 7.28 6.70 1.67 9.61 8.85 1.71 12.07 11.08 1.75 14.68 13.32 1.80 17.66 15.47 1.85 21.09 21.09 1.93 25.00 25.00 2.03 28.67 28.67 2.16
75
700 6.74 6.20 1.74 9.10 8.38 1.80 11.56 10.61 1.87 14.17 12.85 1.93 16.98 14.88 2.01 20.27 20.27 2.11 23.90 23.90 2.23 28.30 28.30 2.39
800 6.86 6.31 1.74 9.23 8.50 1.80 11.70 10.74 1.85 14.33 12.99 1.91 17.19 15.06 1.98 20.53 20.53 2.06 24.32 24.32 2.17 28.58 28.58 2.30
900 6.96 6.41 1.75 9.35 8.60 1.80 11.82 10.85 1.84 14.46 13.12 1.89 17.37 15.22 1.95 20.76 20.76 2.04 24.73 24.73 2.14 28.48 28.48 2.27
50VT
