13
PERFORMANCE DATA (CONT)
030 Coolin g Extended Performance Table
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM / BF EWB
Capacity
MBtuh
To t a l S y s
KW
Capacity
MBtuh
To t a l S y s
KW
Capacity
MBtuh
To t a l S y s
KW
Capacity
MBtuh
To t a l S y s
KW
Capacity
MBtuh
To t a l S y s
KW
Capacity
MBtuh
To t a l S y s
KW
To t a l Sens To t a l Sens To t a l Sens To t a l Sens To t al Sens To t al Sens
875 / 0.05
57 28.47 28.47 1.94 27.21 27.21 2.15 25.85 25.85 2.37 24.39 24.39 2.62 22.78 22.78 2.88 20.95 20.95 3.15
62 29.18 25.42 1.94 27.67 24.95 2.15 26.09 24.39 2.37 24.42 24.42 2.62 22.78 22.78 2.88 20.95 20.95 3.15
63* 29.61 20.60 1.94 28.05 20.16 2.15 26.40 19.65 2.38 24.64 19.08 2.62 22.73 18.41 2.88 20.62 17.62 3.15
67 31.91 21.40 1.95 30.23 20.96 2.16 28.45 20.46 2.38 26.52 19.88 2.63 24.44 19.21 2.89 22.12 18.39 3.16
72 34.97 17.28 1.96 33.11 16.85 2.17 31.12 16.32 2.39 28.99 15.72 2.64 26.68 15.03 2.90 24.10 14.20 3.17
1000 / 0.05
57 29.72 29.72 1.98 28.36 28.36 2.18 26.91 26.91 2.41 25.32 25.32 2.65 23.58 23.58 2.91 21.60 21.60 3.19
62 29.97 27.26 1.98 28.41 28.34 2.18 26.91 26.91 2.41 25.33 25.33 2.65 23.58 23.58 2.91 21.60 21.60 3.19
63* 30.31 21.98 1.98 28.67 21.52 2.18 26.94 21.00 2.41 25.10 20.40 2.65 23.10 19.69 2.91 20.89 18.83 3.18
67 32.64 22.87 1.99 30.88 22.42 2.19 29.00 21.90 2.42 26.98 21.29 2.66 24.80 20.58 2.92 22.39 19.70 3.19
72 35.74 18.21 2.00 33.79 17.74 2.20 31.70 17.19 2.43 29.47 16.56 2.67 27.04 15.84 2.93 24.35 14.99 3.20
1125 / 0.06
57 30.79 30.79 2.01 29.34 29.34 2.22 27.78 27.78 2.44 26.09 26.09 2.69 24.23 24.23 2.95 22.12 22.12 3.22
62 30.79 30.79 2.01 29.34 29.34 2.22 27.79 27.79 2.44 26.09 26.09 2.69 24.23 24.23 2.95 22.12 22.12 3.22
63* 30.85 23.30 2.01 29.15 22.83 2.22 27.36 22.29 2.44 25.44 21.65 2.68 23.38 20.89 2.94 21.11 19.95 3.21
67 33.20 24.29 2.02 31.37 23.82 2.23 29.41 23.28 2.45 27.32 22.64 2.69 25.06 21.88 2.95 22.58 20.93 3.22
72 36.33 19.07 2.03 34.30 18.58 2.24 32.12 18.01 2.46 29.81 17.37 2.70 27.30 16.63 2.96 24.52 15.74 3.23
*At 75_F (23.9 _C) entering dry bulb—Tennessee Valley Authority [TVA] rating conditions; all others at 80_F (26.7 _C) entering dry bulb. See Legend and Notes.
030 Heating Extended Performance Table --10--60 (--23.3--15.6_C)
INDOOR AIR
OUTDOOR CO I L ENTERING AIR TEMPERATURES deg F
--- 1 0 0 10 20 30 40 50 60
EDB CFM
Capacity
MBtuh
Tot a l
Sys
KW
Capacity MBtuh
Tot a l
Sys
KW
Capacity MBtuh
Tot a l
Sys
KW
Capacity MBtuh
Tot a l
Sys
KW
Capacity MBtuh
Tot a l
Sys
KW
Capacity MBtuh
Tot a l
Sys
KW
Capacity MBtuh
Tot a l
Sys
KW
Capacity MBtuh
Tot a l
Sys
KWTot a l Integ Tot a l Integ Tot a l Integ Tota l Integ To ta l Integ To tal Integ To t al Integ To t al Integ
65
875 9.06 8.34 1.90 12.11 11.14 1.98 15.26 14.00 2.04 18.55 16.82 2.12 22.03 19.31 2.19 25.87 25.87 2.28 30.37 30.37 2.39 35.63 35.63 2.54
1000 9.26 8.52 1.92 12.33 11.34 1.99 15.48 14.21 2.05 18.79 17.05 2.10 22.30 19.54 2.17 26.34 26.34 2.24 30.84 30.84 2.34 36.27 36.27 2.47
1125 9.43 8.68 1.94 12.51 11.51 2.00 15.68 14.39 2.05 19.00 17.24 2.10 22.53 19.74 2.16 26.65 26.65 2.22 31.24 31.24 2.31 36.86 36.86 2.43
70
875 8.53 7.85 1.98 11.67 10.73 2.06 14.87 13.65 2.14 18.21 16.51 2.22 21.71 19.03 2.30 25.47 25.47 2.40 29.91 29.91 2.52 35.05 35.05 2.67
1000 8.73 8.03 2.00 11.89 10.94 2.08 15.11 13.87 2.14 18.46 16.74 2.21 21.99 19.26 2.28 25.82 25.82 2.36 30.36 30.36 2.46 35.68 35.68 2.59
1125 8.91 8.20 2.02 12.08 11.11 2.09 15.31 14.05 2.15 18.68 16.94 2.21 22.22 19.47 2.27 26.12 26.12 2.34 30.74 30.74 2.42 36.20 36.20 2.55
75
875 7.95 7.31 2.06 11.18 10.29 2.15 14.45 13.27 2.24 17.84 16.18 2.33 21.38 18.73 2.42 25.11 25.11 2.52 29.46 29.46 2.64 34.49 34.49 2.80
1000 8.15 7.50 2.08 11.40 10.49 2.17 14.70 13.49 2.24 18.10 16.41 2.32 21.66 18.97 2.39 25.43 25.43 2.48 29.90 29.90 2.58 35.09 35.09 2.72
1125 8.33 7.66 2.11 11.60 10.67 2.18 14.90 13.68 2.25 18.32 16.61 2.32 21.89 19.18 2.38 25.72 25.72 2.45 30.27 30.27 2.55 35.60 35.60 2.67
50VT
