Carrier RTU Open - Page 33

33
Field Assistant Navigation
Fig. A — Field Assistant Navigation Chart
Table A — User Interface Menus
Equipment
Touch Menu
Access
Level
3=ADMIN
2=USER
1=No PW
POINT NAME BACnet Object RANGE DEFAULT
Field Assistant
Menu
STATUS
RTU Properties
Menu>
Status
3, 2, 1 Equipment Status mode_status 1=Disable
2=Test
3=Ruin
Properties>
Control Program>
Status
3, 2, 1 SystmMode run_status 1=Off
2=Fan Only
3=Economizer
Cooling
4=Cooling
5=Heating
6=Dehumidification
7=Test
8=Shutdown
9=Unocc Free Cooling
10=Fire Shutdown
11=IAQ Override
12=Pre-occ Purge
13=IGC Override
3, 2, 1 S Fan Status sfan_status Off/Running N/A
N/A Supply Fan Status
1
sfan_status Off/Running
Fan/Speed
2
fan_run 1=Off
2=Low
3=Med
4=High
5=On
3, 2, 1 Supply Fan VFD
3
vfd_output 0-100%
3, 2, 1 Supply Fan VFD
Voltage
vfd_volt_output 0-10v
3, 2, 1 Space Temperature -
Prime Variable
space_temp xxx °F
3, 2, 1 Supply Air
Temperature
sa_temp xxx °F
3, 2, 1 Outdoor Air
Temperature
oa_temp xxx °F
Properties
Equipment
Status
Configuration
Unit Configuration
Setpoints
Alarm Configuration
Service Configuration
Maintenance
Performance
Alarms
Linkage
APPENDIX A — USER INTERFACE MENUS
