Carrier RTU Open User Manual

51
Setpoint R/W °F ADF 8 SNVT_temp_p(105) nviUnoccHtSP
Space Relative Humidity
Sensor
R
0=Normal
1=Alarm
BI 45 SNVT_switch(95) nvoSpRHSenr
Setpoint Adjustment R °F ADF 44 SNVT_temp_p(105) nvoSPAdjust
Effective Heat Setpoint R °F ADF 23 SNVT_temp_p(105) nvoEffHeatSP
Low Fan Econ Min Pos R/W %Open 33 ADF 32 SNVT_lev_percent(81) nviLwFnEcnMn
Fire / Smoke Shutdown R
0=Normal
1=Alarm
BI 32 SNVT_switch(95) nvoFrShtdwn
Reset Filter Alarm R/W
0=Off
1=On
Inactive (0) BO 22 SNVT_switch(95) nviRstFilAlm
Setpoint R/W °F ADF 7 SNVT_temp_p(105) nviUnoccClSP
ZS Sensor Configuration R
0=Normal
1=Alarm
BI 63 SNVT_switch(95) nvoZsCfgFail
Space Relative Humidity R %rh ADF 46 SNVT_lev_percent(81) nvoSpaceRH
Outdoor Air Temperature R °F ADF 38 SNVT_temp_p(105) nvoOAT
Cooling Lockout Temperature R/W °F 45 ADF 16 SNVT_temp_p(105) nviClLckTemp
Power Exhaust Setpoint R/W %Open 50 ADF 43 SNVT_lev_percent(81) nviPwrExhSP
BAS On / Off R/W
1=Inactive
2=Occupied
3=Unoccupied
1 ADI 1 SNVT_count_inc(9) nviBASOnOff
System Space AQ R/W ppm -999 ADF 39 SNVT_count_inc(9) nviSysSpAQ
System Space RH R/W % -999 ADF 40 SNVT_lev_percent(81) nviSysSpRH
Compressor Status R
0=Normal
1=Alarm
BI 30 SNVT_switch(95) nvoCmpSafety
Filter Service Alarm Timer R/W hr 600 ADF 28 SNVT_count_inc(9) nviFltAlmTm
Indoor Air Quality Sensor R
0=Normal
1=Alarm
BI 37 SNVT_switch(95) nvoIAQSensor
Heating Lockout Temperature R/W °F 65 ADF 29 SNVT_temp_p(105) nviHtLckTmp
Dehumidification R
0=Inactive
1=Active
BI 9
Reversing Valve Relay State R
0=Off
1=On
BI 20
Vent Dmpr Pos / DCV Min Pos R/W %Open 20 ADF 60 SNVT_lev_percent(81) nviDCVMinPos
Filter R
0=Clean
1=Dirty
BI 31 SNVT_switch(95) nvoFilter
Safety Chain R
0=Normal
1=Alarm
BI 43 SNVT_switch(95) nvoSftyChain
Unocc Relative Humidity
Setpoint
R/W %rh 95 ADF 59 SNVT_lev_percent(81) nviUnoccRHSP
Setpoint R/W °F ADF 9 SNVT_temp_p(105) nviOccHeatSP
Supply Air Temp Sensor R
0=Normal
1=Alarm
BI 51 SNVT_switch(95) nvoSATSensor
Override Time Remaining R min ADF 41 SNVT_count_inc(9) nvoOvrTmRem
Setpoint Adjustment R/W
0=Disable
1=Enable
Active (1) BO 26 SNVT_switch(95) nviSPAdjEnbl
System Space Temp R/W °F -999 ADF 56 SNVT_temp_p(105) nviSysSpTmp
System Outdoor AQ R/W ppm -999 ADF 63
Outdoor Air Temp Sensor R
0=Normal
1=Alarm
BI 27
SPT Sensor R
0=Normal
1=Alarm
BI 38
Fan / Speed R
1=Off
2=Low
3=Med
4=High
5=On
ADI 4
Setpoint Adjustment Range R/W °^F 5 ADF 45 SNVT_count_inc(9) nviSPAdjRng
Enthalpy (BACnet) R/W
0=High
1=Low
Active (1) BO 6 SNVT_switch(95) nviSysEnth
Optimal Start R/W hr 1 ADF 61 SNVT_count_inc(9) nviOptmStart
Power Fail Restart Delay R/W seconds 5 ADF 58 SNVT_count_inc(9) nviUntStrDly
Table C — Network Points List for N2 and LonWorks (cont)
Point Name
Point
Access
Units
Default
Value
N2 LonWorks
N2 Network
Point Type
N2 Network
Point
SNVT Type SNVT Name
