Example of general programming
Example of general programming
PERIOD 1 PERIOD 2 PERIOD 3 PERIOD 4
Time / Setpoint / Mode Time / Setpoint / Mode Time / Setpoint / Mode Time / Setpoint / Mode
Monday 7,30 => 22° ON 10,45 => 19° ON 12,00 => 20° ON 20,30 => 18° SB
Tuesday 6,30 => 21° SB 10,00 => 20° ON 13,30 => 18° ON 22,00 => OFF
Wednesday 7,30 => 22° ON 10,30 => 19° ON 13,30 => 18° ON 18,00 => OFF
Thursday 5,00 => 20° SB 10,30 => 19° ON 12,30 => 20° ON 20,00 => 20° SB
Friday 7,30 => 22° ON 10,15 => 21° ON 15,00 => OFF
Saturday 11,00 => 18° ON 14,00 => 22° ON
Sunday 3,00 => OFF
Programming example for one week using the four periods provided.
PERIOD 1 PERIOD 2 PERIOD 3 PERIOD 4
Time / Setpoint / Mode Time / Setpoint / Mode Time / Setpoint / Mode Time / Setpoint / Mode
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
Zone programming ...
PERIOD 1 PERIOD 2 PERIOD 3 PERIOD 4
Time / Setpoint / Mode Time / Setpoint / Mode Time / Setpoint / Mode Time / Setpoint / Mode
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
Zone programming ...
