Carson Reflex Wheel Pro2 LCD User Manual

34
GB
CARSON Reflex Wheel Pro 50 050 0034 + 35 + 36 + 37
Connectors:
1. Steering servo (CH1)
2. Throttle servo (CH2)
3. Channel 3 servo (CH3)
4. Channel 4 servo (CH4)
Batt: Power connector
Steckplätze:
1. Steering servo (CH1)
2. Throttle servo (CH2)
3. Channel 3 servo (CH3)
4. Channel 4 servo (CH4)
5. Channel 5 servo (CH 5)
BEC: Power connector or
BEC use
2.4 GHz antenna
LCD display
+/- button
SEL/CH
button
ST D/R
button
TH D/R
button
Power switch
Grip handle
Battery box
Steering wheel
Throttle
trigger
Throttle trim
Steering trim
Switch
“France“ switch
For use in France the switch must
be set to “F“/“Fra“.
Fail safe set
“France“ switch
For use in France the switch must
be set to “F“/“Fra“.
Switch
“Failsafe Pro + SET“
Switch for
3rd channel
Functions
Version Reflex Wheel Pro LCD
Version Reflex Wheel Pro2 LCD
“France“ switch
For use in France the switch
must be set to “F“/“Fra“.
Charger
socket
Throttle rate
adjuster

Carson Reflex Wheel Pro2 LCD Specifications

General

Brand	Carson
Model	Reflex Wheel Pro2 LCD
Category	Remote Control
Language	English
