Carson Reflex Wheel Pro2 LCD User Manual

39
GB
CARSON Reflex Wheel Pro 50 050 0034 + 35 + 36 + 37
Functions
2,4 GHz Antenne
Throttle REV
Steering REV
TH dual rate
ST dual rate
Throttle trim
Steering
trim
Power
Grip handle
Battery box
Steering
wheel
Throttle
trigger
Throttle
rate adjuster
Charger
socket
Throttle trigger
Connectors:
1. Steering servo (CH1)
2. Throttle servo (CH2)
3. Channel 3 servo (CH3)
4. Channel 4 servo (CH4)
Batt: Power connector
Connectors:
1. Steering servo (CH1)
2. Throttle servo (CH2)
3. Channel 3 servo (CH3)
4. Channel 4 servo (CH4)
5. Channel 5 servo (CH 5)
BEC: Power connector for
BEC use
Switch
“France“ switch
For use in France the switch must
be set to “F“/“Fra“.
Fail safe set
“France“ switch
For use in France the switch must
be set to “F“/“Fra“.
Switch
“Fail safe Pro + SET“
Version Reflex Wheel Pro
Version Reflex Wheel Pro2
“France“ switch
For use in France the
switch must be set to
“F“/“Fra“.
