3.3 LAMINATING PRESS DESCRIPTION
CATALOG # 4130CE 4131CE 4132CE
MODEL 150-C 154-M 30-12-L
CLAMP FORCE US TONS
Kn
12
106.8
25
222.5
30
267
MAXIMUM TEMP °
°°
°F
°
°°
°C
500
260
500
260
650
343
PLATENS IN.
MM.
6 x 6
152 x 152
9 x 12
228 x 305
12 x 12
305 x 305
RAM STROKE IN.
MM.
5.125
130
6.5
165
6
152
DAYLIGHT OPENING IN.
MM.
2 @ 3
2 @ 76
2 @ 3
2 @ 76
2 @ 3
2 @ 76
FOOTPRINT W x D IN.
MM.
16 X 18
406 X 459
19 X 19
482 X 482
19 X 19
482 X 482
HEIGHT IN.
MM.
30
761
36
914
42
1066
WEIGHT lbs.
Kg.
190
83
380
166
575
250
NOISE LEVEL
<70db(A) <70db(A) <70db(A)
FULL LOAD CURRENT 115V
240V
12.2A
6.1A
24.4A
12.2A
N/A
22.6A
MAX. SYSTEM PRESSURE PSI
bar
7295
503
9709
669
8488
585
3.4 INSTALLATION
To assist in the installation and operation of this press, an assembly drawing (including part numbers) is included in the
appendix of this manual.
3.5 SETTING UP
Installation Summary:
• Bolt press to bench. DO NOT pump jack without first securing the presses base bolster to an appropriate work
surface to avoid the hazard of tipping over.
• Rotate gauge and tighten coupling.
