Carver Mini C - Electrical; Mold Size Versus Tonnage Chart

Carver Inc 5-3
5.3 ELECTRICAL
WARNING: Before performing any maintenance on the electrical system, turn "OFF" the main electrical
disconnect on the press.
1. Check all electrical connections. Make sure they are tight. Loose connections cause overheating which will
lead to component failures or short circuits.
2. Check all fuses or circuit breakers for open circuits and proper operation.
5.4 MOLD SIZE VERSUS TONNAGE CHART
Maximum tonnage allowed on different mold sizes before platen coining occurs.
MOLD SHAPE MOLD AREA MAXIMUM ALLOWABLE TONS
SQUARE ROUND TONS
IN. CM IN. CM IN.
2
CM
2
SHORT METRIC
3 7.62 7.07 45.62 4.25 3.86
3 7.62 9.00 58.07 5.50 4.99
4 10.16 12.56 81.04 7.50 6.80
4 10.16 16.00 103.23 9.60 8.71
5 12.70 19.64 126.72 11.75 10.66
5 12.70 25.00 161.30 15.00 13.61
6 15.24 28.27 182.40 17.00 15.42
6 15.24 36.00 232.27 21.60 19.59
7 17.78 38.48 248.27 23.00 20.87
7 17.78 49.00 316.15 29.40 26.67
8 20.32 50.27 324.34 30.15 27.35
8 20.32 64.00 412.93 38.40 34.84
9 22.86 63.62 410.48 38.17 34.63
9 22.86 81.00 522.61 48.60 44.09
10 25.40 78.54 506.74 47.12 42.75
10 25.40 100.00 645.20 60.00 54.43
11 27.94 95.03 613.13 57.02 51.73
11 27.94 121.00 780.69 72.60 65.86
12 30.48 113.13 729.91 67.85 61.55
12 30.48 144.00 929.09 86.40 78.38
