CARVIN
®
GOLD SERIES OVAL POOL | USER MANUAL
2
INTRODUCTION
Thank you for purchasing a CARVIN
®
Gold Series Oval Pool (“Product”).
We want to help you get the best results from your new Product and operate it
safely. This manual contains information on how to do that; please read it carefully
before operating the chlorine generator. If a problem should arise, or if you have any
questions about your product, consult an authorized CARVIN
®
retailer or distributor.
All the information in this manual is based on the latest Product information
available at the time of publication. The manufacturer reserves the right to make
changes at any time without notice and without incurring any obligation. No part of
this publication may be reproduced without written permission.
READ AND FOLLOW
ALL INSTRUCTIONS
Review all instructions provided with the product prior to its installation, startup,
operation, shutdown, maintenance or winterization.
Failure to follow warnings and safety messages may result in property damage
or personal injury. The user assumes the bodily or material risks arising from any
improper use of this product.
SAVE THESE INSTRUCTIONS
This manual should be considered a permanent part of the product and should
remain with the product if resold.
IMPORTANT SAFETY INSTRUCTIONS
Your safety and the safety of others are very important.
This manual provides important safety messages. A safety message alerts you to
potential hazards that could hurt you or others. Each safety message is identied by
a black box and one of three words, DANGER, WARNING, or CAUTION.
SUPPORT
To obtain support for this Product, visit carvinpool.com/support and refer to
Consumer Information section of this manual.
This Product is compliant with the following safety standard:
TABLE OF CONTENTS
ICC-ES File PMG-1576
APSP-4 (2012) Standard for Above-ground /
Onground Residential Swimming Pools
Introduction 2
Warning 3
Safety recommendations 3
Pool safety label 3
Pool liner size 3
Installation 4
Tools 4
Required material 4
Preparing the site 4
Ground leveling 5
Trench digging 5
Unpacking the pool parts 6
Assembling the footbeam and buttrest posts 6
Laying the buttrests inside the trenches 7
Assembling pressure plates 7
Assembling the tie straps 7
Squaring out the straight section 8
Fill up the trenches 8
Assemble the bottom feet & rails 8
Assemble the round section rails 9
Wall installation 9
Basin assembly 10
The sand bed 11
Installing the geotextile liner 12
Installing the round section uprights 12
Liner installation 12
Fastening the liner on to the pool wall 13
Structure assembly 13
Installing the top plates - Round sections 13
Installing the top plates - Straight sections 14
Installing the posts covers 14
Installing the ledges 14
Top ledge cover installation 15
Locking the foots in round section 16
Filling the pool with water 16
Inspection 17
Water chemistry 18
Water chemical table 18
Regular cleaning 18
Winterizing the pool 18
Inspection 18
Preparing the water 18
Winterizingtheltrationsystem 18
Use of a winter cover 19
Spring opening 19
Remplacement parts 20
Exploded views 20
Parts table 23
Consumer information 24
Warranty 24
Replacement parts availability 24
Replacement parts warranty 24
Entire written warranty 24
To obtain warranty service 24
Technical support information 24
Disclaimer 24
