GOLD SERIES OVAL POOL | USER MANUAL
23
REMPLACEMENT PARTS
Use the original CARVIN
®
replacement parts only.
#
PART CODE
DESCRIPTION 12x15 12x18 12x21 12x24 15x21 15x24 15x30 18x33 18x39
52’’
1 PGU52 UPRIGHT GOLD SERIES 6 6 6 6 8 8 8 10 10
2 PGL TOP SEAT GOLD SERIES 8 8 8 8 10 10 10 12 12
3 PGPB BOTTOM PLATE GOLD SERIES 6 6 6 6 8 8 8 10 10
4 PGPT TOP PLATE GOLD SERIES 6 6 6 6 8 8 8 10 10
5 PGCF TOP LEDGE COVER FRONT GOLD SERIES 10 12 14 16 14 16 20 22 26
6 PGCB TOP LEDGE COVER BACK GOLD SERIES 10 12 14 16 14 16 20 22 26
7 PGCC TOP LEDGE COVER CAP GOLD SERIES 10 12 14 16 14 16 20 22 26
8 PZRA15 WALL RAIL 15’ 16 16 16 16 20 20 20 24 24
STRAIGHT SECTION METAL PARTS
9 46025008 OVAL POOL FOOT BEAM SHEET METAL 4 6 8 10 6 8 12 12 16
10
46025009
OVAL POOL BUTTRESS POST 4 6 8 10 6 8 12 12 16
11 46025003 OVAL POOL PRESSURE PLATE 2 4 6 8 4 6 10 10 14
12
46025007
OVAL POOL TIE STRAPS SIZE 35’’ 2 3 4 5
46025006 OVAL POOL TIE STRAPS SIZE 40’’ 2 3 4 5 6 8
46025005 OVAL POOL TIE STRAPS SIZE 55’’ 6 8 12 12 16
13
46025010
BOLT BUSHING 12 18 24 30 18 24 36 36 48
STRAIGHT SECTION PLASTIC PARTS
14 OPZPB OVAL POOL STRAIGHT FOOT 4 6 8 10 6 8 12 12 16
15 OPZPT OVAL POOL STRAIGHT TOP PLATE 4 6 8 10 6 8 12 12 16
16 OPZR OVAL POOL STRAIGHT RAIL 4 8 12 16 8 12 20 20 28
17 OPGU52 OVAL POOL POST COVER GOLD SERIES 4 6 8 10 6 8 12 12 16
18 OPGL OVAL POOL STRAIGHT MARGELLE GOLD SERIES 2 4 6 8 4 6 10 10 14
HARDWARE
19 14455045 1/2’’-20-2B HEX NUT - ECO GUARD FINISH 12 18 24 30 18 24 36 36 48
20 14455095
1/2’’ WASHER ID0.515-OD0875-THK0.0625
ECO GUARD FINISH
40 60 80 100 60 80 120 120 160
21 14455035
1/2’’-20 X 3.000’’_HEX HEAD SCREW_PARTIALLY THREADED - ECO
GUARD FINISH
12 18 24 30 18 24 36 36 48
22 14455075 1/4-20 X 1/2’’ HEX HEAD FULLY THREADED ECOGUARD FINISH 8 12 16 20 12 16 24 48 64
23 14455085 1/4”-20-2B HEX NUT ECOGUARD FINISH 8 12 16 20 12 16 24 48 64
24 14433700
#12-11 X 1.000 PHILLIPS PAN HEAD
SHEET METAL SCREW STNSTL316
8 12 16 20 12 16 24 24 32
25 14073852
#12 OVERSIZED WASHER
STNSTL316-ID0.250-OD0.750
16 24 32 40 24 32 48 48 64
26 14455025
SELF-TAPPING SCREW WITH LOCKING
WASHER #12-14X1,25 SS316
40 48 56 64 56 64 80 88 104
27 14455032 PAN HEAD #3 SCREW #12-14 X 1,25’’ SS316 98 130 162 194 144 176 240 254 318
28 02581536 WALLBRACKET SS316 2 2 2 2 2 2 2 2 2
29 14172209 PAN HEAD 1/4-20X0,75’’ SS316 30 30 30 30 30 30 30 30 30
30 14072620 FLANGED NUT 1/4-20 5/16 SS316 30 30 30 30 30 30 30 30 30
31 46025015 EXPANDED POLYSTYRENE BLOCK 8 12 16 20 12 16 24 24 32
POOL WALL
32
PWS521215 12x15 1
PWS521218 12x18 1
PWS521221 12x21 1
PWS521224 12x24 1
PWS521521 15x21 1
PWS521524 15x24 1
PWS521530 15x30 1
PWS521833 18x33 1
PWS521839 18x39 1
