CAS PR Series User Manual

FRONT DISPLAY PCB ASSY
PR-LCD 0
6224IS016220
IC(DRIVER)
TM1622(QFP 52)
1
U1
6515CJ0301500 RESISTOR 1/4W
CFR15K
Ω
(
±
5%)
1 R1
6515CJ010000 RESISTOR 1/4W
CFR100
Ω
(
±
5%)
3 R2~4
6710CAP01040 CONDENSER-CERAMIC 0.1uF/50V 1 CP1,2
LCD PRLCD
3 DP1~17
7801CLW00060
CONNECTOR(WAFER) LW0640-06 (LPH01-06)
2 CN1
7232DR00003A
LAMP LED Ф3-RED RED
1 LED1~15
6110PR600000 FRONT DISPLAY PCB 6110-PR6-0000-0
1
POLE DISPLAY PCB ASSY PR-LCD 0
6224IS016220
IC(DRIVER)
TM1622 (QFP52)
1
U1
6515CJ0301500 RESISTOR 1/4W
CFR15K
Ω
(
±
5%)
1 R1
6515CJ010000 RESISTOR 1/4W
CFR100
Ω
(
±
5%)
3 R2~4
6710CAP01040 CONDENSER-CERAMIC 0.1uF/50V 1 CP1
LCD PRLCD
3 LCD1~3
7801CLW00060
CONNECTOR(WAFER) LW0640-06 (LPH01-06)
1 CN1
6110PR600010 POLE DISPLAY PCB 6110-PR6-0001-0
1

CAS PR Series Specifications

General

Units of Measurement	kg, g, lb, oz
Auto Calibration	Yes
Overload Protection	Yes
Display	LCD
Power Supply	rechargeable battery
Interface	RS-232
Material	Stainless Steel Platter
