Cascade 55K - HYDRAULIC SUPPLY; Fork Positioning Function Requirements; Sideshifting Function Requirements; Reeving and Solenoid Adaption

6
6055911-R8 EN
H
YDRAULIC SUPPLY
GA0365.eps
A
Fork Positioning function: No. 3 hose/No. 4 fittings with
4 mm minimum ID.
Sideshifting function: No. 4 hose/No. 6 fittings with
5 mm minimum ID.
Refer to Cascade Hose & Cable Reel Selection Guide, Part
No. 212199 to select the correct hose reel for the mast and
truck.
Fork Positioning / Sideshifting
A Mast Double Internal Reeving
Solenoid Adaption
A Mast Single Internal Reeving
with RF Hydraulic Control
