Cascade C Series Installation Instructions

4 219990 Rev. 0
NSTALLATION
I
Prepare hoses
A Determine hose lengths required for
hydraulic supply configuration of truck.
B Cut hoses to length and install end fittings
or quick-disconnect kits.
5
INTERNAL HOSE REEVING
Sideshifting / Non-sideshifting
SOLENOID – 6-N-1 CABLE/HOSE REEL
Sideshifting
SSR
SSL
SSR SSL
Back (Driver's) Views
FP0198.ill
FP0200.ill
Close Forks
Spread Forks
FP0199.ill
SSL / Spread Forks
(TANK port)
SSR / Close Forks
(PRESSURE port)
FP0221.ill
Close Forks
Spread Forks
SSR
SSL
Spread Forks
Close Forks
HOSE REELS
55C – Sideshifting / Non-sideshifting
HOSE REELS
100, 120, 150C – Sideshifting / Non-sideshifting
