Cascade F Series Installation Instruction

6028021 Rev. 1 3
NSTALLATION
I
RC1305.ill
RC1302.ill
Install tank return hose
Install a hose from the 3N2 control valve TANK
port to the 'tee' adapter installed in Step 1.
3
To LH Hose Reel
or IHR (CLAMP)
From auxiliary valve
(CLAMP)
Solenoid
Coil
From 'tee' fitting
in truck return line
CLAMP
OPEN
CL
CL CCW CW
TANK
ROTATE
CCW CW
CL
CL CCW CW
TANK
ROTATE
CCW CW
OPEN
CLAMP
ROTATE CCW/
SWING EXTEND
ROTATE CW/
SWING RETRACT
Revolving Connection
End Block
AC0771.ill
Hose Reels
OR
Internal Reeving
3N2
Control
Valve
Truck
Auxiliary
Valve
(ROTATE/SWING)
Truck
Auxiliary
Valve
(CLAMP)
Truck
Pump
Tank Return
Line Adapter
Truck
Relief
Truck
Tank
Solenoid
Coil
(capped -
top or bottom)
'Tee' configuration
CLAMP
ROTATE
ROTATE/SWING
Hoses
CLAMP
Hoses
Truck Auxiliary
Valve Ports
RC1303.ill
Install clamp circuit hoses
Measure and assemble hoses (user-supplied) for
the clamp circuit. Install hoses using straight
fittings wherever possible. Use hose clamps as
necessary to secure hoses and prevent chafing.
Install a hose from the truck auxiliary valve port to
the control valve CLAMP IN port.
Install a second hose from the CLAMP OUT port
to a LH or RH 2-Port hose reel or internal reeving.
Install a third hose from truck auxiliary valve port
to the LH 2-Port hose reel or internal reeving.
4
To Hose
Reel or
IHR
Control
Valve
Return-to-
tank line
4
To RH Hose Reel
or IHR
(ROTATE CCW)
From auxiliary valve
(ROTATE CW)
NOTE: Revolving Connection end block may
have either LH or RH porting for the CLAMP
and ROTATE/SWING circuits (LH CLAMP
circuit shown below).
3N2
Control
Valve
To RH Hose Reel
or IHR (ROTATE CW)
From auxiliary valve
(ROTATE CCW)
