Cascade K Series User Manual

12
6055911-R8 EN
I
NSTALLATION
FP0698.eps
B
D
C
A
GA0005.eps
Tilt backHoist up
Hoist down
Tilt forward
Cycle Fork Positioner functions
12
11
SIDESHIFTING / FORK POSITIONING
WITH SOLENOID VALVE
A Sideshift Left
A Open Forks
(press knob button)
B Sideshift Right
B Close Forks
(press knob button)
• Open and close forks several times. Sideshift (if
equipped) left and right. Check for smoothness
and equal movement.
• Check for operation in accordance with ISO
standards.
• Check for leaks at fittings, valve, cylinders.
SIDESHIFTING /
FORK POSITIONING
A Sideshift Left
B Sideshift Right
C Open Forks
D Close Forks
AUXILIARY VALVE
FUNCTIONS
Install backrest
10
Lubrication
Fork Positioner/Sideshifter is prelubed at
the Factory and requires no lubrication
for installation. Use graphite dry lube for
fork bars as required ('Slip Plate Aerosol',
'GraphoKote' or equivalent).
After use, lubricate fork positioner and
sideshifter as described in Periodic
Maintenance Section in this Manual.
Cascade Backrest–
Tighten to 195 Nm.
For other backrests,
see OEM recommen-
dations.
FP0696.eps
B
A
C
C
D
D
FP0696.eps
A
B
A
A
B
B
WARNING: Truck control handle and
attachment function activation shown here
conforms to ISO 3691 ANSI/ITSDF B56.1
recommended practices. Failure to follow
these practices may lead to serious bodily
injury or property damage. End user, dealer
and OEMs should review any deviation from
the practices for safe operation.
