CHAPTER 1 - GENERAL INFORMATION
1-2
Issued 11-08 Bur S2PV00033ZE01 NA
RIGHT, LEFT, FRONT, AND REAR OF THE MACHINE
The terms Right-hand, Left-hand, Front, and Rear are used in this manual to indicate the sides as they are seen
from the operator's seat when the cab is over the idler wheels.
The following illustration shows the machine in normal TRAVEL position. In normal TRAVEL position, the cab is
over the idler wheels. The travel reduction gears are at the rear of the upper structure.
DC03H142
Figure 1
66
34
55
1
2
1. FRONT 3. RIGHT HAND SIDE 5. TRAVEL REDUCTION GEARS (TRAVEL MOTORS)
2. REAR 4. LEFT HAND SIDE 6. IDLER WHEELS
