Engine-Engineandcrankcase
Engine-Remove
1.Removethehood(1)asindicatedinHood-Remove
(90.100)
2.Removethesplitpins,retainingpinandfrontballast
assembly(1)fromthesupport.
WLAPL4S10C102AA1
3.Unscrewthexingscrews(1)andremovethefront
wheelmudguards(2)(ifapplicable)Dothisonboth
sides.
WLAPL4S10C104A2
4.Removethexingbolts(1)anddetachtheengine
left-handsidepanel(2).Carryoutthesameopera-
tionfortheright−handsidepaneltoo.Removethe
glovecompartment.
WLAPL4S10C105A3
5.Recovertherefrigerantfromthesystemviathe
connections(1)and(2)usingthespecictool
380000315.Detachthepipe(1),clearthesection
ofbracketsandclamps,moveitontothecondenser
((1),5),detachthepipe(2),clearthesectionand
takeittothecab.
WLAPL4S10C106AA4
4753161807/05/2013
10.1[10.001]/5
