Engine-Engineandcrankcase
3.-Takeoutthebolts(1)andtherelatedcompressor
clutchdustcover.
WLAPL4S10C142A2
4.Makesurethatthepolyv(2)beltisperfectlyhoused
onthefanpulley.
5.-Movethebelt(2)neartothecompressorpulleyand,
keepingthetool380200011underthebelt,hookit
ontotheclutchofthecompressorattheinnermost
partsoastoslightlyforcethebelt.
WLAPL4S10C143A3
6.
-Withyourlefthandonthefanandrighthandonthe
tool,movebothclockwisesoastotakethebeltonto
thebeltofthecompressor.
-Putthedustcupbackontothecompressorclutch
andtightenthethreescrewstakingcaretospreada
lmofthreadlockontheendssotheydonotcome
unscrewed.
7.-Whereapplicable,repositiontheviscousjointand
thecoolingfan.
8.-Applytherequiredtorquesettings(seeenginesec-
tion)
9.-Insertthethreehooksofthechainintheeyeletson
theengineand,usingthehoist,lifttheassemblyoff
theplatformsupport.
10.-Positiontheengineonthefrontaxle,tryingtoavoid
incorrectoperationswiththehoistsoasnottolet
theenginefandamagethensoftheradiator,then
jointhetwoassembliestogetherwiththefourretain-
ingboltsandthenecessaryadjusterspacersforthe
monobloc/sumpsupport.
11.-Repositionthemovabletoolfordismantlingtractors
380000569undertheengineandplaceawooden
blockinbetweenthepointofcontactbetweenthe
toolandengine.
4753161807/05/2013
10.1[10.001]/17
