Single wheel brake
Speed (km/h) Below 12 Between 12 & 40 40 & above
Brake logic
Independent brake operation below 40 km/h
Below 12 km/h the independent pedals
can only apply braking to the tractors rear
brakes.
If he aco peed i beeen12 km/h
and 40 km/h and a single pedal is
pressed, the trailer brakes as well as the
selected rear brake applies.
When above 40 km/h the pedal latch
detection would require the pedals to be
locked and all brakes are applied when
braking.
If pedals are unlatched Æ 50km/h is not
possible, pedals must be latched to drive
50!
Unlatched:
Max
40km/h
Latched:
50km/h
