PTO
Both front and rear Power Take Off is controlled by a
switch located on the right hand armrest
Dependant on specifications PTO speeds are either
electrically or mechanically shiftable.
Automatic soft start function is standard on all
models.
Auto PTO function uses the rear/front three point
linkage position to engage and disengage the PTO´s
automatically.
The engage / disengage points can be adjusted to
match different implements by pressing long the
AUTO button (Then you see the values in the A-Pillar
and change it with the manual leveling hitch button
in the ICP) or on the monitor.
Fender mounted PTO switch: < 5 sec. Æ PTO on/off
> 5 sec. Æ permanent on
This PTO intention switch has to be pressed
before operator leaves the tractor for
Stationary PTO work.
If the switch is not depressed prior to
leaving the seat the PTO will stop after 7
seconds.
The intention switch applies to both the
front, and rear PTO as well as the PTO
switch on the fender.
