INTRODUCTION
72308230
SmallWireThreshingModule
Numberofbars
14
Numberofwires
36
WireDiameter
4.76mm(0.19in)
Distancebetweenwires
6.1mm(0.24in)
LargeWireThreshingModule
Numberofbars
14
Numberofwires
15
WireDiameter
6.35mm(0.25in)
Distancebetweenwires
18.4mm(0.7in)
SlottedThreshingModule
Slotlength50mm(1.97in)
Slotwidth25mm(0.98in)
%OpenArea
35
RoundBarThreshingModule
Numberofbars
14
Bardiameter
6mm(0.2in)
Distancebetweenbars
34mm(1.3in)
SmoothThreshingModule
Optional
DischargeBeater
Type3Blade
Speed
800RPM
Width
1285mm(50.6in)
Diameter
476mm(18.7in)
Drive3HBBelt
BeaterConcave
GrateWidth1167mm(45.9in)
WrapAngle
40°
GrateTypeperforatedsheet
Numberofperforations176(22rowsof8)
Openingsize15mm(0.59in)x40mm(1.57in)
SettingSpringloaded
CLEANINGSHOE
FrameWidth
1580mm(62.2in)
CleaningShoeTypeSelfleveling
Drive
1HCbelt
UpperShakerShoe
StandardSpeed
270RPM
GrainPanwidth1571mm(61.9in)
GrainPanlength1320mm(52.0in)
GrainPan+rakesurface2.36m²(3658in²)
Pre-sievewidth
1580mm(62.2in)
Pre-sievelength
757mm(29.8in)
Pre-sievearea(withrake)1.47m²(2278in²)
Uppersievewidth
2x790mm(31in)
Uppersievelength
1446mm(56.9in)
Uppersievearea
2.3m²(3565in²)
Uppersievegratesurface1940cm²(301in²)
LowerShakerShoe
Lowersievelength
1446mm(56.9in)
Lowersievewidth
2x790mm(31.1in)
