INTRODUCTION
72308230
Lowersievearea
22840cm²(3540in²)
Totalsieveareaunderwindcontrol
6.5m²(10075in²)
CLEANINGFAN
Type
Cross-Flow
DriveHydraulic
Fanspeedrange300–1150RPM
SpeedControlClosedLoop
Numberofblades
40
RETURNSYSTEM
TailingsReturnType
TripleImpellerCropProcessor
Crossaugerspeed
548RPM
Bottomimpellerspeed548RPM
Middleimpellerspeed481RPM
Topimpellerspeed657RPM
GRAINTANK,UNLOAD
Centrallling,foldablebubblerStd.
Graintankcapacity11100l(315Bu)12334l(350Bu)
In-cabcontrolofgraintank
extension/covers
Optional
Unloadingconcept
Overthetopunloading
Unloadingtubelength,fromcenterlineofcombine
Standardcapacity6.7m(22ft)
Standardcapacitywith914mm
(36in)extension
7.6m(24ft10in)
Standardcapacitywith1321mm
(52in)extension
8m(26ft2in)
Highcapacity
7.2m(23ft7in)
Highcapacitywithextension
8.8m(28ft8in)
Bubbleupaugerspeed338RPM
Bubbleupaugerspeed-Optional
highspeed(corn)
464RPM
STRAWCHOPPER&SPREADER
Strawchopper(Opt)
Integral-Fixed
Numberofknives-Standardcut
28,2-rowhelix
NumberofcounterknivesStandard
cut
21
40,2-rowhelix
Numberofknives-Finecut
120,3-rowhelix
Numberofcounterknives-Finecut
40
Speed
800RPMlowor3000RPMhigh
ChopperDrive
3HBBelt
Spreadertype
Verticaldualimpeller
Spreaderspeed
350–750RPM
Spreaderdrive
Hydraulic
OptionalDualdiscspreader
Spreadertype
Horizontaldualdisc
Spreaderspeed
100–575RPM
Spreaderdrive
Hydraulic
HYDRAULICSYSTEM
Reservoircapacity
29.5l(7.8USgal)
4804083715/08/2017
28
